Name: Dell XF0X9 Networking S3048-ON 48X 1GbE 4X SFP+ 10GbE Ports Switch
Brand: Dell
SKU: XF0X9
Price: 415.00 USD
Availability: InStock
Rating: 4.8 (119 reviews)

Product Overview
The Dell XF0X9 Networking S3048-ON switch combines a high number of 1GbE ports with several 10GbE uplinks, fitting into networks that need both broad device support and sufficient uplink bandwidth. It's commonly used in enterprise and data center environments to provide access and aggregation. This switch brings together density, speed, and flexibility without unnecessary complexity.

General Information
Brand	Dell
Part Number	XF0X9
Condition	Refurbished

Technical Information
Switch Ports	48
Number of Ports	48-Ports
Port Type	10/100/1000Base-T, 10G SFP+
Port Speed	1 Gbps
UpLink Ports	4
POE Support	No
Switching Capacity	176 Gbps
Switch Forwarding Rate	343.75 Mpps
VLAN Support	Yes
Max VLANs Supported	1-4094
Stackable	No
Layer Support	Layer 3
Connector Type	RJ-45,SFP+

Performance
Jumbo Frame Support	Up To 9216 Bytes
MAC Address Table Size	16000

Management and Configuration
Routing Protocols	Static, RIP, OSPF, BGP, VRRP, IGMP
Remote Protocols	Yes
Management Interfaces	CLI, Web GUI, SNMP, SSH, Telnet, Serial Console (RJ-45), USB Console
Security Features	802.1X, RADIUS, TACACS+, SSH, ACLs, Port Security, Storm Control
Remote Management Protocol	SNMPv1/v2c/v3, SSH, Telnet, HTTP/HTTPS

Power & Cooling
Fans	2 (hot-swappable)

Physical Characteristics
Weight	5.00
Operating Temperature	0°C to 40°C

Miscellaneous
Compliance Standards	WEEE, RoHS, CE, FCC, UL, TUV
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.3ad

Product Description
The Dell Networking S3048-ON switch offers robust wired connectivity with 48 1GbE ports and 4 10GbE SFP+ uplink ports, providing a balanced mix of access and uplink capabilities. It is often found in enterprise networks and data centers where reliable and scalable Ethernet switching is essential. Built for IT professionals and network administrators, this switch supports a range of applications from standard office connectivity to more demanding server access or aggregation layers. It fits well into both traditional and software-defined network setups. Key Features Provides high-density 1GbE port access for numerous endpoints Includes multiple 10GbE uplink ports for enhanced bandwidth Supports advanced Layer 2 and Layer 3 features for versatile networking Offers open networking capabilities compatible with various OS options Efficient design suitable for rack-mounted deployments This switch is typically deployed in mid-sized data centers and enterprise edge environments where a balance between port density and uplink speed is required. Its flexibility allows businesses to scale their network without major overhauls. Users benefit from simplified network management and reliable performance, helping to maintain smooth connectivity across their infrastructure.

Use Cases
The Dell XF0X9 Networking S3048-ON switch is well-suited for environments that require high port density combined with scalable uplink capacity. It is ideal for data centers and enterprise IT infrastructures where numerous 1GbE connections are needed for device access, while also supporting high-speed aggregation over 10GbE links. How It's Used: Aggregating edge devices and servers in enterprise campus networks to ensure reliable connectivity and bandwidth. Serving as a top-of-rack switch in data center deployments to support virtualization and compute clusters. Providing network access for SMBs requiring scalable port capacity with future-proof uplink options. Implementing in edge computing setups where large numbers of IoT devices need consolidated network access. Facilitating storage area network (SAN) edge connectivity through 10GbE uplinks for enhanced data throughput. Supporting remote or branch office networks demanding high port availability with simplified management. This switch contributes to operational efficiency by offering dense port availability alongside flexible uplink scalability. These features enable organizations to optimize network architecture for both current workloads and anticipated growth without compromising performance or manageability.
