| Product Overview |
|---|
The Cisco Catalyst 3850-24XU-L is a Layer 3 managed switch designed to deliver high-speed 10 Gigabit connectivity through 24 SFP+ ports. It fits well in enterprise and data center networks, providing both uplink flexibility and powered device support via UPoE. Its rack-mountable design and network module expansion make it suitable for environments requiring scalable and reliable network infrastructure. |
| General Information | |
|---|---|
| Brand | Cisco |
| Part Number | WS-C3850-24XU-L |
| Condition | Refurbished |
| Technical Information | |
|---|---|
| Switch Ports | 24 |
| Number of Ports | 24-Ports |
| Port Type | 10GBase-T, SFP+, USB Console, Serial Console (RJ-45) |
| Port Speed | 10 Gbps |
| UpLink Ports | 1 |
| POE Support | PoE++ |
| DRAM | 4 GB |
| Flash Memory | 2 GB |
| VLAN Support | Yes |
| Max VLANs Supported | 1-4094 |
| NIM Slot | 1 |
| Stackable | Yes |
| Layer Support | Layer 3 Lite |
| Connector Type | SFP+,RJ-45 |
| Performance | |
|---|---|
| Jumbo Frame Support | Up To 9216 Bytes |
| MAC Address Table Size | 32000 |
| Management and Configuration | |
|---|---|
| Routing Protocols | Static, RIP |
| Remote Protocols | Yes |
| Management Interfaces | Console (RJ-45), USB, CLI (SSH/Telnet), HTTP/HTTPS, SNMP |
| Remote Management Protocol | SSH,Telnet,HTTP,HTTPS,SNMP |
| Routing Protocol | Static,RIP |
| Power & Cooling | |
|---|---|
| Fans | 2 (field-replaceable) |
| Physical Characteristics | |
|---|---|
| Weight | 5.00 |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Miscellaneous | |
|---|---|
| Compliance Standards | WEEE, RoHS, CE, FCC, UL, TUV, cULus |
| Compliant Standards | IEEE 802.3,IEEE 802.3u,IEEE 802.3ab,IEEE 802.3z,IEEE 802.3ae,IEEE 802.1Q,IEEE 802.1p,IEEE 802.1D,IEEE 802.1w,IEEE 802.1s,IEEE 802.3af,IEEE 802.3at,IEEE 802.3bt |
| Product Description |
|---|
The Cisco Catalyst 3850-24XU is built for enterprise networks that need reliable, high-performance switching with advanced management features. Often found in data centers or core distribution layers, it handles heavy traffic loads with ease. Network administrators and IT professionals benefit from its combination of high port density and enhanced routing functions. Key Features
This switch is frequently deployed in enterprise environments, campuses, and data centers where both performance and reliability matter. It simplifies managing large networks and helps maintain smooth data flow across multiple segments. Its power-over-Ethernet capability also reduces the need for separate power supplies, streamlining infrastructure setup. |
