Product Overview |
|---|
The Cisco Catalyst 2960-L Series WS-C2960L-8TS-LL is a Layer 3 managed network switch offering 8 Gigabit Ethernet PoE+ ports alongside 2 SFP uplink ports. It’s designed to provide power and data connectivity in compact rack spaces, suited for business networks requiring manageable and reliable switching. This model fits well in settings such as small enterprise networks and branch offices where flexible connectivity and power delivery to devices like IP phones or access points are needed. |
General Information |
|
|---|---|
| Brand | Cisco |
| Part Number | WS-C2960L-8TS-LL |
| Condition | Refurbished |
Technical Information |
|
|---|---|
| Switch Ports | 8 |
| Number of Ports | 8-Ports |
| Port Type | 10/100/1000Base-T, SFP |
| Port Speed | 10/100/1000Base-T |
| UpLink Ports | 2 |
| POE Support | PoE+ |
| Switching Capacity | 20 Gbps |
| Switch Forwarding Rate | 14.88 Mpps |
| DRAM | 128 MB |
| Flash Memory | 64 MB |
| VLAN Support | Yes |
| Max VLANs Supported | 1-4094 |
| Stackable | No |
| Layer Support | Layer 2+ |
| Connector Type | RJ-45,SFP |
Performance |
|
|---|---|
| Jumbo Frame Support | Up To 9216 Bytes |
| MAC Address Table Size | 8192 |
Management and Configuration |
|
|---|---|
| Routing Protocols | Static |
| Remote Protocols | Yes |
| Management Interfaces | CLI (Console/SSH/Telnet), Web UI (HTTP/HTTPS), SNMP (v1/v2c/v3), RMON |
| Remote Management Protocol | SNMP, SSH, HTTP, HTTPS, Telnet |
| Routing Protocol | Static |
Power & Cooling |
|
|---|---|
| Fans | Fanless |
Physical Characteristics |
|
|---|---|
| Dimensions | 1.73 x 17.5 x 9.45 inches |
| Weight | 5.00 |
| Operating Temperature | 32 to 104 F (0 to 40 C) |
Miscellaneous |
|
|---|---|
| Eco Friendly | Yes |
| Compliance Standards | RoHS, CE, FCC, cULus |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1Q, IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1X |
Product Description |
|---|
The Cisco Catalyst 2960-L Series switch delivers reliable Gigabit Ethernet connections with Power over Ethernet Plus (PoE+) capabilities. It's commonly used in small to medium-sized networks to support devices like IP phones, wireless access points, and security cameras. Built for network administrators who need simple but effective Layer 3 features, this switch offers both manageability and performance suitable for business-grade deployments. It's often found in office wiring closets, branch locations, and enterprise edge setups. Key Features
This switch fits neatly in environments where space is limited but network reliability is critical. By combining Power over Ethernet and Layer 3 capabilities, it supports a range of networked devices while allowing efficient traffic management. You’ll often see it deployed in office floors, retail stores, and branch offices where straightforward, managed network access is necessary. |
