| Product Overview |
|---|
The T3048-LY9-R Quanta switch combines 48 10GBase-T ports and 6 40GbE QSFP+ uplinks to deliver flexible, high-speed connectivity. It sits at the core of enterprise or data center networks where efficient routing and port density are needed. This Layer 3 managed switch helps manage traffic effectively and supports diverse networking setups without unnecessary complexity. |
| General Information | |
|---|---|
| Brand | Quanta |
| Part Number | T3048-LY9-R |
| Condition | Refurbished |
| Technical Information | |
|---|---|
| Switch Ports | 48 x 10GBase-T RJ45, 6 x 40GbE QSFP+ |
| Number of Ports | 48-Ports |
| Port Speed | 10 Gbps, 40 Gbps, 1 Gbps, 100 Mbps |
| Switching Capacity | 1.44 Tbps (1440 Gbps) |
| Switch Forwarding Rate | 1,071.43 Mpps |
| Max VLANs Supported | 4094 |
| Connector Type | RJ45 (10GBase-T), QSFP+ (40GbE) |
| Performance | |
|---|---|
| Jumbo Frame Support | Up To 9216 Bytes |
| Management and Configuration | |
|---|---|
| Security | 802.1X, ACLs, RADIUS, TACACS+, Port Security |
| Remote Management Protocol | SNMPv1/v2/v3, SSH, Telnet, HTTP, HTTPS, RMON |
| Routing Protocol | Static routing, RIP, OSPF |
| Physical Characteristics | |
|---|---|
| Weight | 4.00 |
| Miscellaneous | |
|---|---|
| Compliance Standards | WEEE, RoHS, cURus, CE, FCC, CCC, UL, TUV, cULus, CSA, cUL |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3an, IEEE 802.3x, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.3ad |
| Product Description |
|---|
The T3048-LY9-R is a versatile network switch offering a combination of 10GBase-T and 40GbE QSFP+ ports. It is built for environments that require both high-speed access and robust uplinks, such as data centers and large enterprise networks. Network administrators and IT professionals often rely on this switch to handle demanding traffic loads and support complex network designs. Key Features
This switch is frequently deployed in data centers and enterprise backbones where speed and scalability are crucial. It helps maintain smooth data flow and supports network segmentation, keeping systems responsive under heavy loads. Its combination of copper and fiber connectivity makes it practical for mixed environments requiring reliable and adaptable network infrastructure. |
