| Product Overview |
|---|
The Huawei Quidway S3328TP-EI is a gigabit Ethernet switch that fits well within medium to large-scale business networks. It handles multiple high-speed connections through its 24 Ethernet ports and 2 SFP slots, enabling connections over both copper and fiber. This model delivers Layer 3 routing capabilities, helping networks manage internal traffic efficiently while supporting various management features to keep communications smooth and reliable. |
| General Information | |
|---|---|
| Brand | Huawei |
| Part Number | S3328TP-EI |
| Condition | Refurbished |
| Technical Information | |
|---|---|
| Switch Ports | 24 x 10/100/1000Base-T, 2 x SFP |
| Number of Ports | 24-Ports |
| Port Speed | 10/100/1000Mbps |
| Switching Capacity | 52 Gbps |
| Switch Forwarding Rate | 101.56 Mpps |
| Max VLANs Supported | 4094 |
| Connector Type | RJ-45 (Copper), SFP (Fiber) |
| Performance | |
|---|---|
| Latency | < 10 µs |
| Jumbo Frame Support | Up To 9216 Bytes |
| MAC Address Table Size | 8K (≈8192) |
| Management and Configuration | |
|---|---|
| Management Type | Web GUI, CLI, SNMP, Telnet |
| Security | ACLs, 802.1X, RADIUS, SSH, HTTPS |
| Remote Management Protocol | SNMPv1/v2c/v3, RMON, SSH, Telnet, HTTP, HTTPS |
| Routing Protocol | Static routing, RIP |
| Power & Cooling | |
|---|---|
| Fans | 1 (rear, temperature-controlled) |
| Power | AC 100-240V, 50/60Hz |
| Physical Characteristics | |
|---|---|
| Dimensions | 44 x 440 x 220 mm |
| Weight | 4.00 |
| Operating Temperature | 0°C to 45°C |
| Miscellaneous | |
|---|---|
| Eco Friendly | Yes |
| Assembly Required | Yes |
| Compliance Standards | WEEE, RoHS, cURus, CE, FCC, CCC, UL, TUV, cULus, CSA, cUL |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1D, IEEE 802.1X, IEEE 802.3x |
| Product Description |
|---|
The Huawei Quidway S3328TP-EI is a Layer 3 managed switch that provides reliable gigabit connectivity across multiple devices. It is often found in enterprise networks where stable and efficient data transfer is required. The switch supports 24 Ethernet ports for high-speed connections alongside 2 SFP ports, allowing for flexible fiber link integration. Built for network administrators and IT teams, this switch offers the ability to manage and route traffic effectively within medium to large network environments. Its Layer 3 capabilities make it suitable for segmenting networks and improving overall communication performance. Key Features
This switch is typically deployed in office environments, data centers, and campus networks where dependable gigabit speeds and flexible uplink options are essential. It facilitates smooth data flow and helps maintain network stability in day-to-day operations. By integrating this switch, organizations can benefit from improved network segmentation, better traffic management, and scalable connectivity options suited to evolving network demands. |
