Name: R9L64-61001 HP FlexNetwork 5140 24G PoE+ 24 x Ports 1000Base-T PoE+ + 4 x Ports 10GbE SFP+ 1U Rack-mountable Layer 3 Managed Gigabit Ethernet Network Switch
Brand: HP
SKU: R9L64-61001
Price: 1649.00 USD
Availability: InStock
Rating: 4.8 (119 reviews)

Product Overview
The HP FlexNetwork 5140 24G PoE+ switch combines PoE power delivery with advanced Layer 3 routing in a compact rack-mountable unit. It fits well in enterprise network environments that require both data and power over Ethernet, and supports high-speed uplinks through 10GbE SFP+ ports. This switch suits network setups where flexibility, space, and intelligent traffic handling are important.

General Information
Brand	HP
Part Number	R9L64-61001
Condition	Refurbished

Technical Information
Switch Ports	24
Number of Ports	24-Ports
Port Type	1000Base-T, 10G SFP+
Port Speed	1000Base-T
UpLink Ports	4 x 10GbE SFP+
POE Support	PoE+
Switching Capacity	128 Gbps
Switch Forwarding Rate	95.24 Mpps
DRAM	256 MB
Flash Memory	128 MB
VLAN Support	Yes
Max VLANs Supported	1-4094
Layer Support	Layer 3
Connector Type	RJ-45,SFP+

Performance
Jumbo Frame Support	Up To 9216 Bytes
MAC Address Table Size	32000

Management and Configuration
Routing Protocols	Static, RIP, OSPF, BGP, VRRP, IGMP
Remote Protocols	Yes
Management Interfaces	Web GUI,CLI (Console),SSH,Telnet,SNMP,RMON
Security Features	802.1X,ACLs (Access Control Lists),RADIUS,TACACS+,MAC Authentication,DHCP Snooping,IP Source Guard,Storm Control
Remote Management Protocol	SSH,Telnet,HTTP,HTTPS,SNMP
Routing Protocol	Static,RIP,OSPF,BGP,VRRP,IGMP

Power & Cooling
Power	370W PoE budget

Physical Characteristics
Dimensions	1.73in x 17.44in x 12.99in (44mm x 443mm x 330mm)
Weight	5.00
Operating Temperature	0°C to 45°C

Miscellaneous
Compliance Standards	WEEE, RoHS, CE, FCC, UL, TUV, cULus

Product Description
The HP FlexNetwork 5140 24G PoE+ is designed to handle demanding network environments with both power and data delivery on a single cable. It's commonly used in medium to large enterprise networks, providing connectivity for IP phones, wireless access points, and other PoE-powered devices. This switch is built for network administrators who need precise control over traffic routing and security, often found in wiring closets or data centers where space efficiency and performance are critical. Key Features Offers 24 PoE+ ports to power devices up to the IEEE 802.3at standard Includes 4 10GbE SFP+ ports to handle uplink and stacking demands Supports Layer 3 features such as static routing and dynamic routing protocols Compact 1U rack size optimizes space in network racks Provides extensive management options via CLI, SNMP, and web interface In practice, this switch is often deployed in enterprise wiring closets or small data centers, where it connects user devices and uplinks to core switches or servers. Its power-over-Ethernet capability simplifies installations by reducing the need for additional power cables, while its Layer 3 features allow for advanced traffic management within larger networks.

Use Cases
The HP FlexNetwork 5140 24G PoE+ switch is designed for enterprise networks needing integrated power and data transmission in a compact rack form. It is ideal for IT teams managing environments that require scalable Layer 3 routing and high-speed uplink capacity to support converged networks and demanding workloads. How It's Used: Deploying edge switches in campus environments to power VoIP phones, wireless access points, and surveillance cameras while managing traffic routing. Supporting SMB and branch office networks that require a combination of PoE+ power delivery and 10GbE uplinks for inter-site connectivity. Integrating into data center top-of-rack configurations where high throughput and Layer 3 capabilities optimize storage and server traffic flows. Facilitating network segmentation and routing in enterprise IT closets to improve traffic management and security across multiple VLANs. Enabling network infrastructure for remote offices demanding efficient power management alongside high-speed data aggregation. This switch enhances operational efficiency by consolidating power and data delivery in a single device, reducing cabling complexity. Its Layer 3 features and 10GbE uplink ports support scalable network growth and improved performance across various enterprise network architectures.
