| Product Overview |
|---|
The Netgear ProSafe M4300-52G-PoE+ is a 48-port gigabit Ethernet switch that combines data connectivity with power delivery over Ethernet cables. It fits well into network infrastructures requiring high port counts and PoE+ support, providing reliable performance for powered devices across business networks. |
| General Information | |
|---|---|
| Brand | Netgear |
| Part Number | GSM4352PB-100NES |
| Series | M4300 |
| Model Number | M4300-52G-PoE+ |
| Condition | Refurbished |
| Technical Information | |
|---|---|
| Switch Type | Layer 2, Layer 3, Managed Switch |
| Form Factor | Rack-Mountable |
| Mount Type | 1U Rack |
| Switch Ports | 48 |
| Number of Ports | 52-Ports |
| Port Type | 10/100/1000Base-T, 10G SFP+, RJ-45 |
| Port Speed | 1G |
| UpLink Ports | 2x SFP+ |
| POE Support | PoE+ |
| Switching Capacity | 176 Gbps |
| Switch Forwarding Rate | 130.9 Mpps |
| VLAN Support | Yes |
| Max VLANs Supported | up to 4096 VLANs |
| Stackable | Yes |
| Layer Support | Layer 3 |
| Connector Type | RJ-45, Mini-USB, USB-A |
| Performance | |
|---|---|
| Latency |
0.9µs 10G SFP+ 1.25µs 10G RJ45 |
| Jumbo Frame Support | Up To 9000 Bytes |
| MAC Address Table Size | 16,000 entries |
| Management and Configuration | |
|---|---|
| Routing Protocols | Static, RIP, OSPF, PIM-SM, PIM-DM, IGMP, MLD |
| Remote Protocols | SNMP, Telnet, HTTPS, SSH |
| Management Interfaces | CLI, Web GUI, SNMP, sFlow, RMON, Telnet, SSH, HTTPS |
| Security Features | RADIUS, TACACS+, ACLs, DHCP Snooping, 802.1x |
| Security | 802.1X,RADIUS,TACACS+,Access Control Lists (ACL),BPDU Guard,Storm Control |
| Remote Management Protocol | SNMPv1/v2c/v3,SSH,Telnet,HTTP,HTTPS,RMON,sFlow,Syslog |
| Routing Protocol | Static Routing,RIP,OSPF,VRRP |
| Power & Cooling | |
|---|---|
| Fans | No |
| Power | 100-240V AC 50/60Hz; PoE+ budget up to 740W |
| Power Supply | 1000W Internal, Supports Dual PSU |
| Physical Characteristics | |
|---|---|
| Dimensions | 440 × 388 × 44 mm |
| Weight | 4.00 |
| Operating Temperature | 0°C to 40°C |
| Miscellaneous | |
|---|---|
| Compliance Standards | WEEE, RoHS, CE, FCC, UL, cULus |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.3af, IEEE 802.3at |
| Product Description |
|---|
The Netgear ProSafe M4300-52G-PoE+ is a robust gigabit Ethernet switch designed to manage and power a wide array of network devices. Often found in medium to large business networks, it simplifies connectivity with 48 ports capable of delivering Power over Ethernet Plus (PoE+), ideal for devices like IP phones, wireless access points, and security cameras. Built for IT professionals and network administrators, this switch provides both reliable data transfer and power delivery over a single cable, reducing clutter and installation complexity. Its managed layer 3 capabilities enable advanced network routing and segmentation, making it a solid choice for organizations needing scalable and efficient network infrastructure. Key Features
This switch is typically deployed in office environments, data centers, or network closets where high port density and power delivery are necessary. It plays an important role in supporting VoIP systems, wireless networks, and IP surveillance setups while maintaining efficient network operation. |
| Use Cases |
|---|
The Netgear ProSafe M4300-52G-PoE+ switch is designed for enterprise IT environments requiring robust network infrastructure with integrated power delivery. It suits medium to large office networks, campus environments, and data aggregation points where managed layer 3 capabilities and high port density streamline network segmentation and traffic management. How It's Used:
This switch enhances operational efficiency by consolidating power and data delivery, reducing infrastructure complexity while enabling scalable network growth. Its managed layer 3 features allow IT teams to optimize traffic flows and maintain high availability in demanding network environments. |
