Name: N9K-C93180YC-FX Cisco Nexus 9300 Series 93180YC-FX 48 x Ports 10GBase-X SFP+ + 6 x Ports 40GBase-X QSFP+ 1U Rack-mountable Layer 3 Managed Gigabit Ethernet Network Switch
Brand: Cisco
SKU: N9K-C93180YC-FX
Price: 1499.00 USD
Availability: InStock
Rating: 4.9 (108 reviews)

Product Overview
The N9K-C93180YC-FX Cisco Nexus 9300-FX switch delivers 54-port 1/10/25 Gbps connectivity with 6×40/100 Gbps uplinks, offering 3.6 Tbps capacity, dual 500 W redundant PSUs, and a feature-rich NX‑OS platform ideal for data center spine/leaf, aggregation, and hybrid cloud environments.

General Information
Brand	Cisco
Part Number	N9K-C93180YC-FX
Condition	Refurbished

Technical Information
Switch Type	Managed Switch
Form Factor	Rack-Mountable
Mount Type	1U Rack
Switch Ports	48 x 10/25-Gbps and 6 x 40/100-Gbps QSFP28 ports
Number of Ports	48-Ports
Port Speed	1/10/25 Gbps (SFP28); 40/100 Gbps (QSFP28)
UpLink Ports	6 × QSFP28 (
Switching Capacity	3.6 Tbps
Switch Forwarding Rate	1.2 Bpps
DRAM	64 GB
Flash Memory	128 GB
Max VLANs Supported	Supports up to 4,096 VLAN IDs
Layer Support	Layer 2, Layer 3
Connector Type	SFP28, QSFP28, RJ‑45 MGMT, SFP+ MGMT, USB, RS‑232

Performance
Latency	<1 μs
Jumbo Frame Support	Up To 9216 Bytes
MAC Address Table Size	512,000 entries

Management and Configuration
Routing Protocols	RIP, OSPF, BGP, IS-IS, VRRP
Remote Protocols	NX‑OS CLI, REST API, SNMP, ACI support
Management Interfaces	RJ‑45 MGMT, SFP+ MGMT, USB, RS‑232 console
Security Features	MACsec capable, ACLs, SSH, SNMPv3

Power & Cooling
Fans	4
Power	Typical Power (AC/DC): 260W \| Maximum Power (AC/DC): 425W

Physical Characteristics
Dimensions	1.72 × 17.5 × 19 in
Weight	18.00

Product Description
The N9K-C93180YC-FX is a high-performance, fixed 1RU Layer 2/3 switch in Cisco’s Nexus 9300-FX series, built for modern data center and spine-leaf architectures. Key Features 54 total ports: 48 SFP28 + 6 QSFP28 uplinks 64 GB DRAM, 128 GB SSD for robust control-plane handling Sub‑microsecond latency and jumbo frame support up to 9216 B Supports vPC for MLAG-like redundancy and high availability Embedding NX‑OS CLI, REST API, SNMP, ACI for flexible management Designed for enterprise data centers, cloud-scale environments, and high-throughput environments, it suits aggregation layers, spine/backbone deployments, or virtualized fabric operations. Perfect when you need ultra-low latency, scalability, and advanced protocol support.
