Name: N9K-C93180YC-FX-24 Cisco Nexus 9300 48-Port 10/25GbE & 6-Port 40/100GbE Switch
Brand: Cisco
SKU: N9K-C93180YC-FX-24
Price: 1.00 USD
Availability: InStock
Rating: 4.8 (125 reviews)

Product Overview
The Cisco Nexus 9300 N9K-C93180YC-FX-24 provides 48 fixed 10/25GbE SFP+ ports combined with 6 fixed 40/100GbE QSFP28 ports. This switch fits within data center network architectures, offering high port density and multi-speed options for versatile connectivity and uplink aggregation.

General Information
Brand	Cisco
Condition	Refurbished

Technical Information
Switch Type	Layer 3, Managed Switch
Form Factor	Rack-Mountable
Mount Type	1U Rack
Number of Ports	54-Ports
Port Type	25G SFP28, 40G QSFP+, 100G QSFP28, SFP+, USB Console, Serial Console (RJ-45)
Port Speed	10GbE,25GbE,40GbE,100GbE
UpLink Ports	6 x 40/100GbE QSFP28
POE Support	No
Switching Capacity	3.6 Tbps
Switch Forwarding Rate	7.03 Bpps
DRAM	16 GB
Flash Memory	16 GB
VLAN Support	Yes
Max VLANs Supported	1-4094
Stackable	Optional
Layer Support	Layer 2, Layer 3
Connector Type	SFP+,25G SFP28,QSFP28

Performance
Latency	< 2 µs (typical, line-rate)
Jumbo Frame Support	Up To 9216 Bytes
MAC Address Table Size	32768

Management and Configuration
Routing Protocols	Static, OSPF, OSPFv3, BGP, VRRP, HSRP, PIM-SM, IGMP
Remote Protocols	Yes
Management Interfaces	Console (RJ-45), USB Console, Out-of-band Management Ethernet, SSH, HTTPS, SNMP, NX-API, RESTCONF
Security Features	ACLs,802.1X,RADIUS,TACACS+,SSH,SNMPv3,DHCP Snooping,IP Source Guard,Dynamic ARP Inspection,Role-Based Access Control (RBAC),Secure Boot
Management Type	CLI (NX-OS), SNMP, NX-API, RESTCONF/NETCONF, Web (HTTPS)
Remote Management Protocol	SSH,HTTPS,Telnet (optional),SNMPv2c,SNMPv3,NETCONF,RESTCONF,NX-API
Routing Protocol	Yes

Power & Cooling
Fans	Front-to-back variable-speed hot-swappable fans (redundant)
Power	AC: 100-240 VAC, 50-60 Hz (typical system consumption varies by configuration)
Power Supply	Dual hot-swappable AC power supplies (redundant)

Physical Characteristics
Dimensions	1.72 x 17.32 x 26.46 in
Weight	3.00
Operating Temperature	0°C to 40°C (32°F to 104°F)

Miscellaneous
Eco Friendly	Yes
Assembly Required	No
Compliance Standards	WEEE, RoHS, cURus, CE, FCC, UL, TUV

Product Description
The Cisco Nexus 9300 N9K-C93180YC-FX-24 is a fixed switch designed to deliver high-density 10/25 Gigabit Ethernet connectivity alongside 40/100 Gigabit Ethernet uplinks. It is commonly used in data center environments requiring scalable and flexible network infrastructures. IT professionals and network engineers benefit from this switch by integrating it into leaf-spine architectures or as a top-of-rack solution to support demanding workloads and large-scale virtualized environments. Key Features 48 SFP+ ports with 10/25GbE support for diverse server and storage connectivity 6 QSFP28 ports enabling 40/100GbE uplink capability Fixed switch design tailored for data center deployments Part of the Cisco Nexus 9300 family ensuring compatibility within Cisco ecosystems Advanced networking features to support modern data center requirements This switch plays a crucial role in building scalable and high-throughput network fabrics. Its port density and speed options allow for effective aggregation of server traffic and support for large bandwidth demands, making it suitable for enterprise and cloud data centers.

Use Cases
This switch is typically deployed in data centers where high-density 10/25GbE connectivity is needed alongside 40/100GbE uplink capacity. It supports environments with demanding bandwidth requirements, such as virtualization, large-scale computing, and storage networks. How It's Used: As a top-of-rack switch aggregating server and storage traffic with 10/25GbE connections In leaf-spine network designs providing high-speed uplinks via 40/100GbE QSFP28 ports Within cloud data centers to facilitate scalable and flexible network fabrics Supporting workloads requiring mixed-speed connectivity options for diverse devices Integrating into Cisco Nexus 9300 series deployments for consistent network management The N9K-C93180YC-FX-24 switch fulfills a key role in modern data centers by enabling efficient traffic aggregation and high-capacity uplinks. Its fixed configuration simplifies deployment while supporting a range of network speeds essential for varied data center applications.

FAQ's
What port types does the N9K-C93180YC-FX-24 support? This switch supports 48 10/25GbE SFP+ ports and 6 40/100GbE QSFP28 ports, offering both server connectivity and uplink options. Is the N9K-C93180YC-FX-24 a modular or fixed switch? The N9K-C93180YC-FX-24 is a fixed form-factor switch, meaning its ports are built-in and not modular. Which Cisco series does this switch belong to? It is part of the Cisco Nexus 9300 series, which is designed for data center network deployments. Can this switch be used for 100GbE uplinks? Yes, it provides 6 QSFP28 ports that support 40/100GbE speeds suitable for uplinks. What environments typically use this switch? This switch is used primarily in data center environments requiring high-density 10/25GbE access and 40/100GbE uplinks. Does the switch support both 10GbE and 25GbE on the same ports? Yes, the 48 SFP+ ports support both 10GbE and 25GbE speeds depending on the connected transceivers.
