| Product Overview |
|---|
The MSN3700-CS2RC switch offers 32 high-speed 100G QSFP28 ports packed into a 1U rack-mountable unit designed for Layer 3 switching environments. It fits into data center racks and provides advanced routing and management features suited for large-scale network infrastructures, helping maintain efficient and reliable connectivity where speed and control are priorities. |
| General Information | |
|---|---|
| Brand | Mellanox |
| Part Number | MSN3700-CS2RC |
| Condition | Refurbished |
| Technical Information | |
|---|---|
| Switch Ports | 32 |
| Number of Ports | 32-Ports |
| Port Type | 100G QSFP28, USB Console, Serial Console (RJ-45) |
| Port Speed | 100Gbps |
| POE Support | No |
| Switching Capacity | 6.4 Tbps |
| Switch Forwarding Rate | 4.76 Bpps |
| VLAN Support | Yes |
| Max VLANs Supported | 1-4094 |
| Stackable | No |
| Layer Support | Layer 3 |
| Connector Type | QSFP28 |
| Performance | |
|---|---|
| Jumbo Frame Support | Up To 9216 Bytes |
| Management and Configuration | |
|---|---|
| Routing Protocols | Static, RIP, OSPF, OSPFv3, BGP, IS-IS, VRRP, HSRP, PIM-SM, IGMP, MLD, Policy-Based Routing (PBR), Route Maps |
| Remote Protocols | Yes |
| Management Interfaces | CLI (SSH/Telnet), Web GUI, SNMP, Serial Console (RJ-45), USB |
| Security Features | ACLs, 802.1X, RADIUS, TACACS+, SSH, SNMPv3, MACsec |
| Management Type | In-band and Out-of-band |
| Security | Yes |
| Remote Management Protocol | SSH,HTTPS,HTTP,Telnet,SNMPv1/v2c/v3,REST API |
| Power & Cooling | |
|---|---|
| Fans | Hot-swappable redundant fans (front-to-back airflow) |
| Power | AC 100-240V, 50/60Hz, dual hot-plug redundant PSUs supported |
| Power Supply | Dual hot-plug AC power supplies (redundant) |
| Physical Characteristics | |
|---|---|
| Dimensions | 1.73 x 17.32 x 20.00 inches (43.9 x 440 x 508 mm) |
| Weight | 5.00 |
| Operating Temperature | 0°C to 40°C |
| Miscellaneous | |
|---|---|
| Compliance Standards | WEEE, RoHS, CE, FCC, UL, TUV |
| Compliant Standards | IEEE 802.3, IEEE 802.3ae, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1D |
| Product Description |
|---|
The MSN3700-CS2RC is a high-performance Ethernet switch designed to deliver robust network connectivity with 32 QSFP28 ports supporting 100G speeds. Commonly used in data centers and enterprise networks, it enables efficient handling of large data flows and low-latency communication. Built for network engineers and IT professionals managing complex infrastructures, this switch offers a managed Layer 3 environment that supports advanced routing protocols and network segmentation. It's often found in environments where space efficiency and reliable high-speed switching are crucial. Key Features
Typically deployed in data centers, cloud service environments, and enterprise core networks, the MSN3700-CS2RC helps maintain smooth data flow and network segmentation. It plays a key role in supporting high-bandwidth applications and improving overall network performance. |
