JL825-61001 HP FlexNetwork 5140 48-Ports 10/100/1000Base-T RJ-45 PoE+ 2-Ports 10GBase-X SFP+ Layer 3 Rack-mountable 1U Gigabit Ethernet Switch

SKU:
JL825-61001
Weight: 5.00 lbs
Condition: Refurbished
  • 48 Gigabit Ethernet RJ-45 ports with PoE+ support
  • 2 SFP+ slots for 10G uplinks
  • Layer 3 routing capabilities for advanced network management
  • 1U rack-mountable design suitable for data centers
In stock

$3,000.00

Product Overview

The HP FlexNetwork 5140 switch combines 48 PoE+ capable Gigabit Ethernet ports with two 10G SFP+ slots, making it a solid choice for organizations needing reliable connectivity and power delivery. It fits into a standard 1U rack space and offers Layer 3 routing functions, positioning it as a versatile switch for both access and aggregation layers in enterprise networks.

General Information

Brand HP
Part Number JL825-61001
Condition Refurbished

Technical Information

Switch Ports 48
Number of Ports 48-Ports
Port Type 10/100/1000Base-T, SFP+
Port Speed 10/100/1000Base-T
UpLink Ports 2 x 10G SFP+
POE Support PoE+
Switching Capacity 176 Gbps
Switch Forwarding Rate 130.95 Mpps
DRAM 512 MB
Flash Memory 128 MB
VLAN Support Yes
Max VLANs Supported 4094
Layer Support Layer 3
Connector Type RJ-45,SFP+

Performance

Jumbo Frame Support Up To 9216 Bytes
MAC Address Table Size 32,000 entries

Management and Configuration

Routing Protocols Static, RIP, OSPF, OSPFv3, BGP, VRRP, PIM-SM, IGMP, Policy-Based Routing (PBR)
Remote Protocols Yes
Management Interfaces CLI (Console RJ-45), Web GUI, SNMPv1/v2c/v3, SSH, Telnet, RMON
Security 802.1X, ACLs, DHCP Snooping, IP Source Guard
Remote Management Protocol SNMPv1/v2c/v3, SSH, Telnet, HTTPS, CLI (Console)
Routing Protocol Static,RIP,OSPF,OSPFv3,BGP,VRRP

Power & Cooling

Fans 2 (hot-swappable, variable speed)

Physical Characteristics

Dimensions 1U rack-mountable (approx. 44 x 440 x 300 mm)
Weight 5.00
Operating Temperature 0°C to 45°C

Miscellaneous

Eco Friendly Yes
Compliance Standards WEEE, RoHS, CE, FCC, UL, TUV, cULus
Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1D, IEEE 802.1w, IEEE 802.1X


Product Description

The HP FlexNetwork 5140 switch delivers robust network performance with its 48 PoE+ enabled Gigabit Ethernet ports, making it ideal for powering devices like IP phones, cameras, and wireless access points directly through the network cable. This switch is often found in enterprise data centers and campus networks where reliable, high-speed connections are critical.

Built for IT professionals managing medium to large networks, it supports advanced Layer 3 routing, enabling efficient traffic management and better network segmentation. It's designed to fit neatly into standard 1U rack spaces, optimizing physical infrastructure.

Key Features

  • High-density PoE+ ports provide power and connectivity in one cable
  • Dual 10G SFP+ uplinks facilitate fast backbone connections
  • Layer 3 features support dynamic routing protocols for network flexibility
  • Compact rack-mount design saves space in network racks
  • Energy-efficient technology helps reduce power usage

This switch is commonly deployed in office environments and data centers where space and power management are priorities. It helps deliver consistent network performance while simplifying device installations by providing power through Ethernet.

By combining high port density with 10G uplinks, it supports growing network demands without requiring frequent hardware upgrades.


Use Cases

The HP FlexNetwork 5140 switch is predominantly deployed in enterprise IT environments requiring both high-density Gigabit connectivity and advanced routing capabilities. It is well-suited for organizations that manage complex internal networks with PoE-dependent devices or require scalable uplink speeds for aggregation layers.

How It's Used:

  • Supporting VoIP and IP surveillance systems in corporate campus networks with integrated PoE+ power delivery.
  • Serving as an access layer switch in medium to large data centers where 1G endpoints connect to 10G aggregation uplinks.
  • Facilitating inter-VLAN routing and traffic segmentation in multi-department enterprise LANs.
  • Providing network backbone connectivity in remote branch offices that demand robust Layer 3 functionalities.
  • Integrating with virtualization environments to ensure efficient and managed traffic flow between virtualized servers and storage nodes.

This switch enhances operational efficiency by consolidating power and data delivery in a single device while supporting scalable network growth through its 10G uplinks and Layer 3 routing. It caters to environments where optimized bandwidth management and device power provisioning are critical to maintaining network performance.
