Name: JL384-61001 HP OfficeConnect 1920S 24G 2SFP PPoE+ 12 x RJ-45 Ports PoE+ 10/100/1000Base-T + 12 x RJ-45 Ports + 2 x SFP Ports Layer 2 Managed Rack-mountable Gigabit Ethernet Network Switch
Brand: HPE
SKU: JL384-61001
Price: 553.05 USD
Availability: InStock
Rating: 4.8 (119 reviews)

Product Overview
The HP OfficeConnect 1920S 24G switch fits into small and medium business networks needing versatile, managed connectivity with PoE+ power. It combines multiple Gigabit Ethernet ports with SFP uplinks, enabling network admins to connect and power a variety of devices easily while managing traffic through Layer 2 controls.

General Information
Brand	HPE
Part Number	JL384-61001
Condition	Refurbished

Technical Information
Switch Ports	24 x RJ-45, 2 x SFP
Number of Ports	24-Ports
Port Type	10/100/1000Base-T, 1000Base-X, SFP, Serial Console (RJ-45)
Port Speed	10/100/1000Base-T
UpLink Ports	2 x SFP (1000Base-X)
POE Support	PoE+
Switching Capacity	56 Gbps
Switch Forwarding Rate	41.67 Mpps
DRAM	256 MB
Flash Memory	64 MB
VLAN Support	Yes
Max VLANs Supported	1-4094 (4094)
Stackable	No
Layer Support	Layer 2
Connector Type	RJ-45, SFP

Performance
Jumbo Frame Support	Up To 9216 Bytes
MAC Address Table Size	8K MAC address table (approx.)

Management and Configuration
Routing Protocols	Static
Remote Protocols	Yes
Management Interfaces	Web GUI (HTTP/HTTPS), CLI (console), SNMPv1/v2c/v3, SSH, Telnet, RMON
Security Features	802.1X authentication, ACLs, MAC-based security, DHCP Snooping, IP Source Guard, Storm Control, BPDU Guard, Port Security
Security	802.1X, MAC Filtering
Remote Management Protocol	SNMPv1/v2c/v3, HTTP/HTTPS, SSH, Telnet, RMON
Routing Protocol	Static

Power & Cooling
Power	AC 100-240V, 50/60Hz; PoE budget approx. 370 W

Physical Characteristics
Dimensions	Approx. 44 x 440 x 240 mm (H x W x D)
Weight	5.00
Operating Temperature	0°C to 50°C

Miscellaneous
Eco Friendly	Yes
Compliance Standards	WEEE, RoHS, CE, FCC, UL, cULus
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1D, IEEE 802.3x, IEEE 802.1w

Product Description
The HP OfficeConnect 1920S 24G switch is built for small to medium business networks needing reliable, managed connectivity. It is often found in office server rooms or wiring closets where both data and power delivery to devices like IP phones and wireless access points is required. Designed for network administrators, this switch supports Layer 2 features to help organize and optimize traffic across the network. Its mix of PoE+ enabled ports and SFP slots provides flexibility to connect various devices while reducing the need for separate power sources. Key Features Supports up to 24 PoE+ ports delivering power and data simultaneously Includes 2 SFP ports for uplink or fiber connections Enables VLAN creation and QoS for traffic prioritization Offers web and SNMP management for easy configuration and monitoring Compact rack-mount form factor fits standard network racks This switch is commonly deployed in office networks powering IP phones, wireless access points, and surveillance cameras. It simplifies infrastructure by providing a single point for both network connectivity and power, helping streamline setup and reduce cable clutter.

Use Cases
The HP OfficeConnect 1920S 24G switch is designed for small to medium-sized business environments requiring reliable, managed network connectivity with Power over Ethernet capabilities. It is well-suited for office networks that need to support a mix of wired devices and fiber uplinks while maintaining efficient traffic control. How It's Used: Deploying in SMB office floors to connect IP phones, wireless access points, and security cameras with PoE+ power supply. Integrating into branch office networks requiring managed VLAN segmentation and Quality of Service for multimedia traffic. Supporting fiber-connected uplinks to data centers or main sites using SFP ports in campus environments. Facilitating rack-mounted network infrastructure in small enterprise IT closets with centralized management. Enabling secure and efficient edge switching for remote sites with controlled bandwidth and device prioritization. This switch aids operational efficiency by combining power delivery and Layer 2 management in a single device, allowing network administrators to scale connectivity while maintaining control over traffic flows and device provisioning. Its flexibility in port types and rack-mount design supports growing network demands with minimal disruption.
