Name: JH382A HP FlexFabric 5900-24 24 SFP+ 10GBase-X 2 QSFP+ 40GbE Layer 3 Switch
Brand: HP
SKU: JH382A
Price: 5921.08 USD
Availability: InStock
Rating: 4.8 (119 reviews)

Product Overview
The JH382A HP FlexFabric 5900 Series 5930-24 is a rack-mountable Layer 3 switch offering 24 SFP+ ports for 10 Gigabit fiber connections and 2 QSFP+ ports for 40 Gigabit uplinks. It fits well in environments that require advanced routing, high port density, and fiber optic connectivity, providing a solid foundation for scalable and managed Ethernet networks.

General Information
Brand	HP
Condition	Refurbished

Technical Information
Switch Type	Layer 3, Managed Switch, Gigabit Switch
Form Factor	Rack-Mountable
Mount Type	1U Rack
Switch Ports	24
Number of Ports	24-Ports
Port Type	10G SFP+, 40G QSFP+, USB Console, Serial Console (RJ-45)
Port Speed	10G SFP+,40G QSFP+
UpLink Ports	2
POE Support	No
Switching Capacity	640 Gbps
Switch Forwarding Rate	952.38 Mpps
VLAN Support	Yes
Max VLANs Supported	1-4094
Layer Support	Layer 3
Connector Type	SFP+,QSFP / QSFP+,USB Console,Serial Console (RJ-45)

Performance
Jumbo Frame Support	Up To 9216 Bytes
MAC Address Table Size	32K

Management and Configuration
Routing Protocols	Static, RIP, OSPF, BGP, VRRP, PIM-SM, IGMP
Remote Protocols	Yes
Management Interfaces	Web UI,CLI (SSH/Telnet),SNMP (v1/v2c/v3),RMON,REST API
Security Features	Access Control Lists (ACLs),802.1X,MAC Authentication,SSH,SSL,IP Source Guard,DHCP Snooping,Dynamic ARP Inspection
Management Type	Managed
Remote Management Protocol	SNMP,SSH,Telnet,HTTP,HTTPS,REST

Physical Characteristics
Weight	3.00
Operating Temperature	0°C to 45°C

Miscellaneous
Assembly Required	No
Compliance Standards	WEEE, RoHS, CE, FCC, UL
Compliant Standards	IEEE 802.3,IEEE 802.3u,IEEE 802.3ab,IEEE 802.3z,IEEE 802.3ae,IEEE 802.1Q,IEEE 802.1p,IEEE 802.3ad,IEEE 802.1D,IEEE 802.1w

Product Description
The JH382A HP FlexFabric 5900 Series 5930-24 is a versatile Layer 3 Ethernet switch designed for modern network infrastructures. It is commonly found in enterprise networks and data centers where high bandwidth and reliable connectivity are essential. Built for IT professionals and network administrators, this switch offers advanced management and routing features that support complex network topologies. Its fiber-optimized ports cater to environments that require long-distance and high-speed data transmission. Key Features Offers a total of 24 SFP+ ports suitable for 10Gbps fiber connections Includes 2 QSFP+ ports enabling 40Gbps uplink capacity Supports Layer 3 routing protocols for enhanced network traffic management Designed for rack-mount installation, facilitating integration into standardized network racks Equipped with robust management tools for streamlined network configuration and monitoring This switch plays an integral role in delivering reliable network performance with its blend of port density, speed, and routing capabilities. It supports operational stability and can handle demanding network loads without compromising throughput.

Use Cases
The JH382A HP FlexFabric 5900 Series 5930-24 is typically deployed in data centers and enterprise network cores where high-speed fiber interconnects and Layer 3 routing are essential. It is suited for network teams managing dense virtualization infrastructures and storage clusters requiring low latency and high throughput. How It's Used: Core aggregation switch in medium to large data center environments Edge switch in enterprise networks supporting 10GbE fiber uplinks Backbone connectivity within campus networks integrating diverse subnets Supporting high-density virtualization hosts and storage area networks Handling traffic routing and segmentation with Layer 3 capabilities in complex topologies By integrating this switch into network architectures, organizations can maintain efficient data flow and scalability. Its combination of fiber ports and routing features contributes to stable network performance and easier scalability in demanding environments.
