Name: JG850A#AC4 HP FlexNetwork 5900AF-48XGT-4QSFP+ 48x10GBase-T 4xQSFP+ Layer 3 Switch
Brand: HP
SKU: JG850A#AC4
Price: 27934.06 USD
Availability: InStock
Rating: 4.8 (119 reviews)

Product Overview
The HP FlexNetwork 5900AF-48XGT-4QSFP+ switch provides high-density 10GBase-T access combined with 40Gbps QSFP+ uplinks, fitting into mid-to-large scale network environments. It integrates Layer 3 capabilities to support advanced routing and traffic management, making it suitable for aggregation or core roles in rack deployments.

General Information
Brand	HP
Condition	Refurbished

Technical Information
Switch Type	Layer 3, Managed Switch, Gigabit Switch
Form Factor	Rack-Mountable
Mount Type	1U Rack
Switch Ports	48
Number of Ports	48-Ports
Port Type	10GBase-T
Port Speed	10 Gbps,40 Gbps
UpLink Ports	4
POE Support	No
Switching Capacity	1.28 Tbps
Switch Forwarding Rate	952.4 Mpps
DRAM	2 GB
Flash Memory	2 GB
VLAN Support	Yes
Max VLANs Supported	1-4094
Stackable	Yes
Layer Support	Layer 3
Connector Type	RJ-45,QSFP+

Performance
Jumbo Frame Support	Up To 9216 Bytes
MAC Address Table Size	32000

Management and Configuration
Routing Protocols	Static, RIP, OSPF, BGP, VRRP, HSRP, PIM-SM, IGMP
Remote Protocols	Yes
Management Interfaces	Web (GUI),Command Line Interface (CLI),SSH,Telnet,SNMP,Console (RJ-45),USB
Security Features	Access Control Lists (ACLs),802.1X authentication,SSH,IP-MAC binding,Port security,Storm control,DoS protection
Management Type	In-band and Out-of-band
Remote Management Protocol	SNMP,SSH,Telnet,HTTP,HTTPS

Power & Cooling
Fans	Hot-swappable fans (front-to-back cooling)
Power	Internal AC 100-240VAC, 50-60Hz
Power Supply	Internal AC power supply (single); optional redundant PSU

Physical Characteristics
Dimensions	1.73 x 17.32 x 18.50 in
Weight	3.00
Operating Temperature	0°C to 45°C

Miscellaneous
Assembly Required	No
Compliance Standards	WEEE, RoHS, CE, FCC, UL, cULus
Compliant Standards	IEEE 802.3,IEEE 802.3ab,IEEE 802.3an,IEEE 802.1Q,IEEE 802.1p,IEEE 802.1D,IEEE 802.1s,IEEE 802.3ad,IEEE 802.3x,IEEE 802.1w

Product Description
The HP FlexNetwork 5900AF-48XGT-4QSFP+ is built for network environments requiring robust Layer 3 switching with high port density and multi-gigabit performance. It is commonly found in data centers and enterprise aggregation layers where scalable bandwidth and advanced routing are essential. Network engineers and IT teams benefit from its rich feature set and flexible deployment options. Key Features Supports 48 10GBase-T RJ-45 ports providing flexible connectivity for servers and endpoints Includes 4 QSFP+ ports capable of 40Gbps uplinks for high-speed backbone integration Offers Layer 3 routing protocols including OSPF and BGP for dynamic network management Equipped with advanced QoS and security features to maintain network integrity and performance Designed as a rack-mountable unit suitable for dense network deployments Designed to handle demanding network loads, this switch delivers reliable performance and flexibility for evolving infrastructures. Its Layer 3 capabilities and port configuration streamline network design while supporting operational efficiency and scalability. The unit's form factor and management options make it an adaptable choice for various network architectures.

Use Cases
This switch is typically deployed in enterprise data centers and campus networks where high throughput and reliable routing are required. IT professionals managing complex network topologies find it valuable for consolidating access and uplink traffic with simplified management. It is well-suited for environments demanding scalable bandwidth and Layer 3 functionality. How It's Used: Aggregation layer switch for enterprise campus networks connecting multiple access switches Data center top-of-rack deployment supporting server connectivity with 10GBase-T ports Core or distribution switch in mid-sized network infrastructures requiring Layer 3 routing Network backbone uplinks leveraging 40Gbps QSFP+ interfaces for high-speed data transfer Environments needing integrated QoS and security management to maintain service levels By combining high port density and advanced features, this switch helps maintain efficient network operations and supports growth in bandwidth demands. Its versatility aids administrators in managing diverse workloads with consistent performance across various network segments.
