Name: JG254-61201 HP Flex Fabric 5800-24G-Poe+ 24 PoE+ RJ-45 4 SFP+ 10GbE Layer 3 Switch
Brand: HP
SKU: JG254-61201
Price: 921.08 USD
Availability: InStock
Rating: 4.8 (119 reviews)

Product Overview
The JG254-61201 HP Flex Fabric 5800 Series switch combines 24 PoE+ RJ-45 ports with four SFP+ 10GbE uplinks, delivering power and high-speed connectivity in a rack-mountable design. It fits well in managed Layer 3 network environments requiring reliable routing and flexible deployment options.

General Information
Brand	HP
Condition	Refurbished

Technical Information
Switch Type	Layer 3, Managed Switch, Stackable Switch, PoE Switch, Gigabit Switch
Form Factor	Rack-Mountable
Mount Type	1U Rack
Switch Ports	24
Number of Ports	28-Ports
Port Type	10/100/1000Base-T, 10G SFP+
Port Speed	1 Gbps,10 Gbps
UpLink Ports	4 x SFP+ (10G)
POE Support	PoE+
Switching Capacity	128 Gbps
Switch Forwarding Rate	250 Mpps
DRAM	1024 MB
Flash Memory	512 MB
VLAN Support	Yes
Max VLANs Supported	4094
Stackable	Yes
Layer Support	Layer 3
Connector Type	RJ-45,SFP+

Performance
Jumbo Frame Support	Up To 9216 Bytes
MAC Address Table Size	32000

Management and Configuration
Routing Protocols	Static, RIP, OSPF, BGP, VRRP, PIM-SM, IGMP
Remote Protocols	Yes
Management Interfaces	Web GUI,CLI (Console),SSH,Telnet,SNMP (v1/v2c/v3),Console (RJ-45),USB
Security Features	ACLs,802.1X port authentication,Port security,MAC limiting,DHCP snooping,IP Source Guard,Dynamic ARP Inspection,Storm control,SSH
Management Type	In-band and Out-of-band (CLI, Web GUI, SNMP, Console)
Security	Yes
Remote Management Protocol	SNMPv1/v2c/v3,SSH,Telnet,HTTP,HTTPS
Routing Protocol	Static,RIP,OSPF,BGP,VRRP

Power & Cooling
Fans	2 (hot-swappable, front-to-back airflow)
Power	AC 100-240V, 50/60Hz; PoE budget ~370W
Power Supply	Internal AC power supply (single)

Physical Characteristics
Weight	3.00
Operating Temperature	0°C to 45°C

Miscellaneous
Eco Friendly	Yes
Assembly Required	No
Compliance Standards	RoHS, CE, FCC, cULus
Compliant Standards	IEEE 802.3,IEEE 802.3u,IEEE 802.3ab,IEEE 802.3ae,IEEE 802.3af,IEEE 802.3at,IEEE 802.1Q,IEEE 802.1p,IEEE 802.1X

Product Description
This HP Flex Fabric 5800 Series switch offers robust network performance with a combination of 24 PoE+ enabled RJ-45 ports and four 10GbE SFP+ uplinks. It's commonly found in modern network infrastructures where power delivery over Ethernet alongside high-speed data transfer is needed. Built for IT professionals managing mid-size to larger enterprise networks, it supports advanced Layer 3 routing features that facilitate efficient traffic management and network segmentation. The switch is often chosen to ensure both power and data needs are met efficiently in a single device. Key Features Supports up to 30W PoE+ power per port to power devices directly from the switch Four 10G SFP+ slots provide scalable uplink options for increased bandwidth Advanced Layer 3 capabilities enable dynamic routing and network segmentation Compact rack-mountable form factor designed for efficient space use in data centers Managed switch functionality allows detailed configuration and network control This switch plays a key role in consolidating power and network connectivity, reducing the need for separate power sources for endpoints. Its reliable performance and advanced features make it a consistent choice for networks requiring both flexibility and scalability.

Use Cases
The JG254-61201 switch is typically deployed in enterprise and campus networks where powering devices like IP phones, cameras, or access points directly from the switch is essential. Its combination of PoE+ and high-speed uplinks makes it suitable for environments demanding both data throughput and power delivery. How It's Used: Supporting VoIP phone systems in corporate office networks requiring centralized power and data Providing uplink bandwidth for storage clusters or virtualization environments via 10GbE ports Deploying in campus wiring closets to manage traffic between building floors and segments Powering wireless access points in dense environments while maintaining network segmentation Integrating into data center edge networks needing Layer 3 routing and PoE capabilities By combining power delivery with advanced networking features, this switch helps maintain operational efficiency and scalability in complex network environments. It supports seamless traffic management and device connectivity without additional power infrastructure.
