Name: JE073-61101 HP FlexNetwork 5120-16G 16-Port 10/100/1000Base-T + 4 SFP Layer-4 Managed Switch
Brand: HP
SKU: JE073-61101
Price: 408.72 USD
Availability: InStock
Rating: 4.8 (118 reviews)

Product Overview
The JE073-61101 HP FlexNetwork 5120-16G is a managed gigabit switch that fits within enterprise-grade network infrastructures. It handles multiple high-speed Ethernet connections while providing Layer-4 management to control traffic and enhance security. This model supports a mix of copper and fiber connectivity, making it adaptable to various network designs.

General Information
Brand	HP
Condition	Refurbished

Technical Information
Switch Type	Managed Switch, Gigabit Switch
Form Factor	Rack-Mountable
Mount Type	1U Rack
Switch Ports	16
Number of Ports	20-Ports
Port Type	10/100/1000Base-T, 1000Base-X, RJ-45, SFP, USB Console, Serial Console (RJ-45)
Port Speed	10/100/1000Base-T,1000Base-X
UpLink Ports	4
POE Support	No
Switching Capacity	40 Gbps
Switch Forwarding Rate	78.125 Mpps
DRAM	128 MB
Flash Memory	16 MB
VLAN Support	Yes
Max VLANs Supported	1-4094
Stackable	Optional
Layer Support	Layer 4
Connector Type	RJ-45,SFP,USB Console,Serial Console (RJ-45)

Performance
Jumbo Frame Support	Up To 9216 Bytes
MAC Address Table Size	8192

Management and Configuration
Routing Protocols	Static, RIP, OSPF
Remote Protocols	Yes
Management Interfaces	Web GUI (HTTP/HTTPS),CLI (Console/SSH),SNMP v1/v2c/v3,Telnet,USB Console
Security Features	802.1X,ACLs,Port Security,DHCP Snooping,IP Source Guard,ARP Inspection,Storm Control
Management Type	Managed
Remote Management Protocol	SNMPv1/v2c/v3,SSH,HTTPS,Telnet
Routing Protocol	Static,RIP,OSPF (dependent on firmware/license)

Power & Cooling
Fans	Internal dual hot-swappable fans
Power	100-240 VAC, 50/60 Hz
Power Supply	Internal AC Power Supply

Physical Characteristics
Dimensions	1.7 x 17.3 x 9.8 in (approx.)
Weight	3.00
Operating Temperature	0°C to 45°C

Miscellaneous
Assembly Required	No
Compliance Standards	WEEE, RoHS, CE, FCC, UL, cULus
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1X

Product Description
The HP FlexNetwork 5120-16G switch is designed to provide robust and manageable network connectivity in medium-sized IT environments. It is commonly found in network access layers where reliable gigabit connections and flexible uplink options are essential. Built for IT professionals and network administrators, this switch offers granular control over traffic and security policies. Key Features Supports 16 RJ-45 ports with 10/100/1000Base-T speeds for high-speed wired connections Equipped with 4 SFP slots allowing for scalable fiber or copper uplinks Incorporates Layer-4 management capabilities for enhanced traffic prioritization and security Offers advanced VLAN and QoS functions to optimize network performance Designed for efficient integration into existing HP FlexNetwork ecosystems This switch plays a practical role in maintaining consistent network throughput and managing complex traffic flows. Its reliable hardware and comprehensive management features make it a valuable asset in structured network environments where performance stability is critical.

Use Cases
This switch is typically deployed in enterprise network access layers, providing dependable gigabit connections with flexible uplink options for diverse environments. It benefits IT teams requiring detailed traffic management and integration with larger HP network systems. How It's Used: Enabling gigabit access for office workstations in medium enterprise LANs Uplink aggregation via SFP modules in campus network distributions Supporting VLAN segmentation and QoS in multi-department IT setups Integrating with HP FlexNetwork architecture for centralized management Deploying in edge computing sites requiring managed switching solutions By addressing the needs for scalable connectivity and advanced traffic control, the switch contributes to efficient network operation and scalability. Its reliability and management features help maintain smooth data flow in professional IT environments.
