| Product Overview |
|---|
The J9586AR - HP 3800-48G-4XG offers a solid balance between high port density and advanced Layer 3 routing capabilities, making it suitable for enterprise settings where both flexibility and reliability are necessary. It fits into network architectures that demand efficient traffic handling and robust connectivity options without unnecessary complexity. |
| General Information | |
|---|---|
| Brand | HP |
| Condition | Refurbished |
| Technical Information | |
|---|---|
| Switch Type | Layer 3, Managed Switch, Stackable Switch, Gigabit Switch |
| Form Factor | Rack-Mountable |
| Mount Type | 1U Rack |
| Switch Ports | 48 |
| Number of Ports | 48-Ports |
| Port Type | 10/100/1000Base-T, 10G SFP+, RJ-45, SFP+ |
| Port Speed | 1Gbps,10Gbps |
| UpLink Ports | 4 |
| POE Support | No |
| Switching Capacity | 176 Gbps |
| DRAM | 1 GB |
| Flash Memory | 128 MB |
| VLAN Support | Yes |
| Max VLANs Supported | 1-4094 (up to 4094 VLANs) |
| Stackable | Yes |
| Layer Support | Layer 3 |
| Connector Type | RJ-45,SFP+ |
| Performance | |
|---|---|
| Jumbo Frame Support | Up To 9216 Bytes |
| MAC Address Table Size | 32000 |
| Management and Configuration | |
|---|---|
| Routing Protocols | Static, RIP, OSPF, OSPFv3, BGP, VRRP, PIM-SM, IGMP |
| Remote Protocols | Yes |
| Management Interfaces | CLI,Web GUI (HTTP/HTTPS),SNMPv1/v2/v3,SSH,Telnet,Serial Console (RJ-45),USB Console |
| Security Features | ACLs,802.1X port security,MAC authentication,RADIUS,TACACS+,SSH/SSL,IP Source Guard,DHCP Snooping |
| Management Type | Managed |
| Security | Yes |
| Remote Management Protocol | SNMPv1/v2/v3,SSH,Telnet,HTTP,HTTPS,CLI |
| Routing Protocol | Layer 3 |
| Power & Cooling | |
|---|---|
| Fans | Variable-speed fans (front-to-back) |
| Power | AC 100-240V, internal |
| Power Supply | Internal AC power supply (100-240V) |
| Physical Characteristics | |
|---|---|
| Dimensions | 1.73 x 17.32 x 17.8 in |
| Weight | 3.00 |
| Operating Temperature | 0°C to 45°C |
| Miscellaneous | |
|---|---|
| Eco Friendly | Yes |
| Assembly Required | No |
| Compliance Standards | WEEE, RoHS, CE, FCC, UL, TUV, cULus |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1X |
| Product Description |
|---|
The J9586AR - HP 3800-48G-4XG is a Layer 3 switch built to handle demanding network environments that require both high port density and advanced routing functions. It is commonly found in enterprise network cores or distribution layers where efficient traffic management and scalability are essential. Engineered for network administrators and IT professionals, this switch supports a mix of high-speed connections and sophisticated protocol handling, making it suitable for organizations needing reliable and flexible network infrastructure. Key Features
This switch delivers consistent performance and dependable connectivity, ensuring that network traffic flows smoothly even under heavy loads. Its combination of switching and routing functions allows it to play a crucial role in maintaining network stability and performance. Overall, the J9586AR fits well within infrastructures that require both high capacity and advanced management, making it a practical choice for growing or complex enterprise networks. |
| Use Cases |
|---|
This Layer 3 switch is often utilized in enterprise data centers and distribution layers where network segmentation and routing efficiency are critical. It benefits IT teams managing medium to large networks that require a blend of high-speed ports and advanced routing capabilities. How It's Used:
The J9586AR supports operational efficiency by providing robust routing and switching functionalities tailored for complex network demands. Its design helps IT environments scale while maintaining performance and security. |
