Name: ICX7650-48F-E Brocade 7650 24x 10GbE SFP+ 24x 40GbE QSFP Switch
Brand: Brocade
SKU: ICX7650-48F-E
Price: 4947.05 USD
Availability: InStock
Rating: 4.8 (118 reviews)

Product Overview
The ICX7650-48F-E combines 24 10GbE and 24 40GbE ports to offer a versatile solution for modern network demands. It fits well in environments that require both high port density and flexible high-speed uplinks, balancing performance with connectivity options in core and aggregation network roles.

General Information
Brand	Brocade
Condition	Refurbished

Technical Information
Switch Type	Layer 3, Managed Switch, Stackable Switch, Gigabit Switch
Form Factor	Rack-Mountable
Mount Type	1U Rack
Number of Ports	48-Ports
Port Type	SFP+, QSFP / QSFP+, USB Console, Serial Console (RJ-45)
Port Speed	10Gbps,40Gbps
UpLink Ports	4 x 40Gbps QSFP+
POE Support	No
Switching Capacity	1280 Gbps
VLAN Support	Yes
Max VLANs Supported	4094
Stackable	Yes
Layer Support	Layer 3
Connector Type	SFP+,QSFP+,RJ-45 (Console/Management)

Performance
Jumbo Frame Support	Up To 9216 Bytes
MAC Address Table Size	32000

Management and Configuration
Routing Protocols	Static, RIP, RIPng, OSPF, OSPFv3, BGP, VRRP, PIM-SM, IGMP
Remote Protocols	Yes
Management Interfaces	Console (RJ-45), USB, SSH, Telnet, HTTP/HTTPS, SNMP
Security Features	ACLs, 802.1X, RADIUS, TACACS+, Port Security, SSH, SSL
Management Type	In-Band and Out-of-Band
Remote Management Protocol	SNMPv1/v2c/v3, SSH, Telnet, HTTP, HTTPS

Power & Cooling
Fans	Hot-swappable redundant fans
Power	AC 100-240V, 50-60Hz
Power Supply	Internal AC (single, optional redundant available)

Physical Characteristics
Weight	3.00
Operating Temperature	0°C to 40°C

Miscellaneous
Assembly Required	No
Compliance Standards	RoHS, CE, FCC, UL
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad, IEEE 802.1D

Product Description
The ICX7650-48F-E is a high-performance network switch built to handle demanding data center and enterprise environments. It combines 24 10 Gigabit Ethernet ports with 24 40 Gigabit QSFP ports, offering flexible connectivity options for various network setups. This switch is often found in core or aggregation layers where robust traffic management and high-speed data transfer are essential. Engineered for network administrators and IT professionals, it supports extensive Layer 2 and Layer 3 routing capabilities to facilitate complex network architectures. Its design emphasizes scalability and reliability, making it suitable for organizations requiring consistent network performance. Key Features Non-blocking architecture ensures full throughput without congestion Supports both IPv4 and IPv6 routing protocols for future-proof networking Multiple QoS levels enable prioritized traffic handling High-density port configuration maximizes network consolidation Advanced security features help protect network integrity This switch delivers dependable connectivity and efficient data handling in a compact form factor. Its performance and feature set provide a solid foundation for building resilient and scalable network infrastructures.

Use Cases
The ICX7650-48F-E is typically deployed in data centers and enterprise campuses where high throughput and port density are needed. It benefits network teams managing virtualization platforms, storage clusters, and high-bandwidth applications that demand low latency and reliable connections. How It's Used: Aggregation layer in large enterprise networks requiring 10GbE and 40GbE connectivity Data center leaf switch supporting server and storage traffic in virtualized environments High-density core switch for campus networks with mixed traffic profiles Edge switch in distribution networks connecting multiple access switches Backbone infrastructure for storage area networks needing high-speed links By integrating this switch, organizations can enhance their network's operational efficiency and scalability. It supports demanding workloads while maintaining stable performance and simplified management.
