Product Overview |
|---|
The ICX6610-24P-PE is a 24-port Gigabit Ethernet switch designed to provide power and data connectivity in enterprise and campus environments. It supports Power over Ethernet Plus (PoE+) across all ports, enabling it to power devices like IP phones and access points while handling data traffic efficiently. Its stacking capabilities allow it to integrate seamlessly into larger network setups, providing scalability and streamlined management. |
General Information |
|
|---|---|
| Brand | Brocade |
| Condition | Refurbished |
Technical Information |
|
|---|---|
| Switch Type | Layer 3, Managed Switch, Stackable Switch, PoE Switch, Gigabit Switch |
| Form Factor | Rack-Mountable |
| Mount Type | 1U Rack |
| Switch Ports | 24 |
| Number of Ports | 24-Ports |
| Port Type | 10/100/1000Base-T, 10G SFP+ |
| Port Speed | 10/100/1000Base-T,10G SFP+ |
| UpLink Ports | 4 x 10G SFP+ |
| POE Support | PoE+ |
| Switching Capacity | 128 Gbps |
| Switch Forwarding Rate | 250 Mpps |
| DRAM | 1 GB |
| Flash Memory | 512 MB |
| VLAN Support | Yes |
| Max VLANs Supported | 4096 |
| Stackable | Yes |
| Layer Support | Layer 3 |
| Connector Type | RJ-45,SFP+ |
Performance |
|
|---|---|
| Jumbo Frame Support | Up To 9216 Bytes |
| MAC Address Table Size | 16000 |
Management and Configuration |
|
|---|---|
| Routing Protocols | Static, RIP, OSPF, VRRP, PIM-SM, IGMP |
| Remote Protocols | Yes |
| Management Interfaces | CLI (Console/SSH),Web GUI,SNMP (v1/v2/v3),RMON |
| Security Features | 802.1X,ACLs,Port Security,MAC Filtering,DHCP Snooping,IP Source Guard,Storm Control |
| Management Type | Managed |
| Remote Management Protocol | SNMPv1/v2/v3,SSH,Telnet,HTTP/HTTPS |
| Routing Protocol | Static,RIP,OSPF |
Power & Cooling |
|
|---|---|
| Fans | 1 (variable speed, front-to-back) |
| Power | AC 100-240V, 50-60Hz, internal power supply |
| Power Supply | Internal AC power supply |
Physical Characteristics |
|
|---|---|
| Weight | 3.00 |
| Operating Temperature | 0°C to 45°C |
Miscellaneous |
|
|---|---|
| Eco Friendly | Yes |
| Assembly Required | No |
| Compliance Standards | RoHS, CE, FCC, UL, cULus |
| Compliant Standards | IEEE 802.3,IEEE 802.3u,IEEE 802.3ab,IEEE 802.1Q,IEEE 802.1p,IEEE 802.3ad,IEEE 802.1D,IEEE 802.1w |
Product Description |
|---|
The ICX6610-24P-PE is a versatile networking switch designed to provide reliable, high-speed connectivity in various network environments. It offers 24 Gigabit Ethernet ports with Power over Ethernet Plus (PoE+) support, enabling both data and power delivery over a single cable. This switch is often found in enterprise and campus network infrastructures where flexibility and scalability are important. Built for network administrators and IT professionals, the ICX6610-24P-PE supports stacking and a range of Layer 2 and Layer 3 features, making it suitable for complex network designs. Its robust management options cater to users who demand granular control and efficient network operation. Key Features
This switch plays a vital role as a dependable network building block, balancing performance with manageable power consumption. Its stacking and advanced protocol support ensure consistent operation even as network demands grow. With a focus on delivering steady throughput and adaptable deployment options, the ICX6610-24P-PE offers an effective solution for maintaining network performance and reliability over time. |
Use Cases |
|---|
The ICX6610-24P-PE is commonly deployed in mid-sized enterprise networks, campus environments, and branch offices where high-density PoE+ support and stacking are needed. It suits organizations that require reliable network performance combined with flexible expansion options. How It's Used:
The ICX6610-24P-PE supports efficient and scalable network operations by combining power delivery with high-capacity switching. Its design enables streamlined management and consistent performance across expanding network infrastructures. |
