| Product Overview |
|---|
The HP OfficeConnect 1910-16G is a Layer 3 managed switch that combines multiple Gigabit Ethernet ports with SFP slots to provide flexible, high-speed networking. It fits well in small business settings where both copper and fiber connections are required, enabling efficient network management and routing without complexity. |
| General Information | |
|---|---|
| Brand | HP |
| Part Number | JE005A |
| Condition | Refurbished |
| Technical Information | |
|---|---|
| Switch Ports | 16 |
| Number of Ports | 20-Ports |
| Port Type | 10/100/1000Base-T, SFP, Serial Console (RJ-45) |
| Port Speed | 10/100/1000Base-T |
| UpLink Ports | 4 |
| POE Support | No |
| Switching Capacity | 40 Gbps |
| Switch Forwarding Rate | 78.125 Mpps |
| DRAM | 128 MB |
| Flash Memory | 16 MB |
| VLAN Support | Yes |
| Max VLANs Supported | 4094 |
| Stackable | No |
| Layer Support | Layer 2+ |
| Connector Type | RJ-45,SFP |
| Performance | |
|---|---|
| Jumbo Frame Support | Up To 9216 Bytes |
| MAC Address Table Size | 8192 |
| Management and Configuration | |
|---|---|
| Routing Protocols | Static, RIP, IGMP |
| Remote Protocols | Yes |
| Management Interfaces | Web (HTTP/HTTPS), CLI (SSH/Telnet), SNMPv1/v2c |
| Security Features | 802.1X,Access Control Lists (ACL),SSH,SSL,MAC Address Filtering,Storm Control |
| Security | Yes |
| Remote Management Protocol | HTTP,HTTPS,SSH,TELNET,SNMP |
| Routing Protocol | Static,RIP |
| Power & Cooling | |
|---|---|
| Fans | Fanless |
| Power | 12.5 W |
| Physical Characteristics | |
|---|---|
| Dimensions | 1.73 x 17.32 x 8.66 in |
| Weight | 3.00 |
| Operating Temperature | 0°C to 40°C |
| Miscellaneous | |
|---|---|
| Compliance Standards | RoHS, CE, FCC, cULus |
| Compliant Standards | IEEE 802.3,IEEE 802.3u,IEEE 802.3ab,IEEE 802.3x,IEEE 802.1Q,IEEE 802.1p,IEEE 802.1D,IEEE 802.3ad |
| Product Description |
|---|
The HP OfficeConnect 1910-16G network switch provides reliable and efficient connectivity for small to medium-sized business networks. It is commonly used in office environments to connect multiple devices with high-speed Gigabit Ethernet ports, while also offering fiber options through its SFP slots. IT administrators and network managers benefit from its Layer 3 features, which help in managing and routing traffic efficiently within the network. Key Features
This switch is often found in office racks or network closets, serving as a central hub for wired connections. It plays a key role in maintaining stable network performance and helps businesses keep their communication infrastructure running smoothly. |
