Name: FESX624 Brocade Fastiron Edge X Switch 24-Port Gigabit Layer 2/3
Brand: Brocade
SKU: FESX624
Price: 627.00 USD
Availability: InStock
Rating: 4.8 (118 reviews)

Product Overview
The FESX624 Brocade Fastiron Edge X Switch combines fiber and copper port options to provide flexible connectivity in edge network setups. It fits environments where a mix of media and Layer 2/3 features is necessary for handling traffic efficiently while maintaining network reliability and control.

General Information
Brand	Brocade
Condition	Refurbished

Technical Information
Switch Type	Layer 2, Managed Switch, Gigabit Switch
Form Factor	Rack-Mountable
Mount Type	1U Rack
Switch Ports	20
Number of Ports	24-Ports
Port Type	10/100/1000Base-T, SFP, USB Console, Serial Console (RJ-45)
Port Speed	10/100/1000Base-T
UpLink Ports	4 x SFP (shared)
POE Support	No
Switching Capacity	48 Gbps
Switch Forwarding Rate	35.7 Mpps
DRAM	128 MB
Flash Memory	64 MB
VLAN Support	Yes
Max VLANs Supported	1-4094
Stackable	No
Layer Support	Layer 2
Connector Type	RJ-45,SFP,Serial Console (RJ-45),USB Console

Performance
Jumbo Frame Support	Up To 9216 Bytes
MAC Address Table Size	8000

Management and Configuration
Remote Protocols	Yes
Management Interfaces	CLI (console/SSH),Web (HTTP/HTTPS),SNMP (v1/v2c/v3),Telnet,RMON
Security Features	802.1X,ACLs,Port Security,SSH,SSL,DHCP Snooping
Management Type	Managed
Remote Management Protocol	SNMPv1/v2c/v3,SSH,Telnet,HTTP,HTTPS

Power & Cooling
Fans	1 (internal, forced-air)
Power Supply	Internal AC 100-240V

Physical Characteristics
Dimensions	1.73 x 17.32 x 9.84 inches
Weight	3.00
Operating Temperature	0°C to 40°C (32°F to 104°F)

Miscellaneous
Assembly Required	No
Compliance Standards	RoHS, CE, FCC, UL
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1D, IEEE 802.1w, IEEE 802.3x

Product Description
The FESX624 Brocade Fastiron Edge X Switch is built for delivering dependable connectivity and advanced network control at the edge of enterprise and service provider networks. It is commonly found in access or aggregation layers where medium-density port counts and versatile interface options are needed. This switch often serves network engineers and IT professionals who require a balance of performance and management features in a compact form factor. It supports standard protocols and offers flexibility for integrating fiber and copper connections. Key Features Provides 24 total ports with 4 shared SFP slots for fiber flexibility Supports robust Layer 2 switching capabilities along with Layer 3 routing functions Equipped with traffic prioritization and QoS controls to ensure efficient data flow Offers resilient hardware design for continuous network uptime Includes comprehensive management options for easier integration and monitoring This switch plays a practical role in facilitating smooth network operations, especially at network edges requiring multiple port types and moderate throughput. Its consistent performance and protocol support help maintain stable, manageable environments.

Use Cases
The FESX624 switch is typically deployed in enterprise branch offices, campus network edges, and mid-sized data center access layers. Its port mix and feature set benefit IT teams requiring adaptable connectivity and manageable switching platforms in these environments. How It's Used: Connecting end-user devices and uplinking to core networks in campus edge installations Providing fiber and copper interface options in branch office local area networks Serving as aggregation points in mid-sized data centers handling mixed traffic types Supporting segmentation and routing within distributed enterprise networks Enabling quality of service and traffic shaping in network edge deployments By supporting diverse connection types and layered network functions, this switch helps maintain efficient and scalable network infrastructure. It supports operational stability and growth without requiring overly complex management.
