| Product Overview |
|---|
The EX4400-48MP switch offers a solid mix of multi-gigabit ports and powerful uplinks designed for modern enterprise networks. It fits well in environments needing both high-speed access and efficient power delivery to connected devices. Its managed Layer 3 features give network administrators the tools to control traffic and maintain reliable performance across complex setups. |
| General Information | |
|---|---|
| Brand | Juniper Networks |
| Part Number | EX4400-48MP |
| Condition | Refurbished |
| Technical Information | |
|---|---|
| Switch Ports | 48 |
| Number of Ports | 48-Ports |
| Port Type | 10GBase-T, 25G SFP28, 100G QSFP28, 2.5GBase-T |
| Port Speed | 2.5G,10G,25G,100G |
| UpLink Ports | 4 x 25GbE,2 x 100GbE |
| POE Support | PoE+ |
| Switching Capacity | 1.44 Tbps |
| Switch Forwarding Rate | 1,072 Mpps |
| DRAM | 8 GB |
| Flash Memory | 8 GB |
| VLAN Support | Yes |
| Max VLANs Supported | 4094 |
| Stackable | Yes |
| Layer Support | Layer 3 |
| Connector Type | RJ-45,SFP28,QSFP28 |
| Performance | |
|---|---|
| Latency | Approximately 2 µs (microsecond-class latency) |
| Jumbo Frame Support | Up To 9216 Bytes |
| MAC Address Table Size | 32,000 |
| Management and Configuration | |
|---|---|
| Routing Protocols | Static, OSPF, OSPFv3, BGP, VRRP, PIM-SM, IGMP |
| Remote Protocols | Yes |
| Management Interfaces | CLI,Web UI (J-Web),SSH,SNMP,NETCONF |
| Security Features | 802.1X,ACLs,Port security,MAC limiting,DDoS protection |
| Remote Management Protocol | SSH,SNMP,NETCONF |
| Routing Protocol | Static,OSPF,OSPFv3,BGP,VRRP,IGMP |
| Power & Cooling | |
|---|---|
| Fans | 4 redundant hot-swappable fans |
| Power | 100-240V AC, 50/60 Hz; PoE+ budget up to 1440 W (platform dependent) |
| Power Supply | Dual hot-swappable AC power supplies (2 x 750 W typical, 1+1 redundant) |
| Physical Characteristics | |
|---|---|
| Dimensions | 1.72 x 17.4 x 17.6 in (43.6 x 442 x 447 mm) |
| Weight | 5.00 |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Miscellaneous | |
|---|---|
| Eco Friendly | Yes |
| Assembly Required | Yes |
| Compliance Standards | RoHS, CE, FCC, UL, cULus |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3bz (2.5G), IEEE 802.3ae, IEEE 802.3az (Energy Efficient Ethernet), IEEE 802.1Q, IEEE 802.1p, IEEE 802.1D, IEEE 802.1w, IEEE 802.1X, IEEE 802.3af, IEEE 802.3at |
| Product Description |
|---|
The EX4400-48MP is a versatile network switch designed to deliver high-performance connectivity with flexible port options. Often found in enterprise and campus networks, it combines multi-gigabit access ports with high-speed uplinks to handle diverse traffic demands. Built for IT teams managing growing wired and wireless environments, this switch supports Power over Ethernet Plus (PoE+) to power devices like access points and IP cameras directly from the switch. Its Layer 3 capabilities allow for routing between VLANs and support for dynamic protocols, making it a strong fit for complex network setups. Key Features
This switch is typically deployed in enterprise wiring closets and data centers where space and power efficiency matter. It helps streamline network infrastructure by combining high port density and routing in a single unit, reducing the need for additional equipment. |
