0KMCCD

Connectors: Two internal HD Mini-SAS SFF8643.

Device Support: Up to 255 devices (SAS, SATA).

Host Bus Type: 8-lane, PCI Express 3.0 compliant.

Data Transfer Rates: Up to 12Gbps per port.

SAS Controller: LSI SAS 3108 1200MT/s PowerPC 476 dual-core 12Gbps ROC.

Cache Memory: 1GB 1333MT/s DDR3 SDRAM.

RAID Management: CTRL-R; Dell OpenManage Storage Services.

Additional Management: UEFI (HII); CEM.

Operating Temperature: Maximum ambient temperature: 60°C.

Operating Voltage: +3.3V.

Optional SSD Optimization: Dell FastPath™ firmware feature: delivers high IOPs performance on SSD arrays.

Operating Systems: Microsoft® Windows Server® 2008 R2 SP1; Microsoft Windows Server 2012; Microsoft Windows Server 2012 R1 & R2; Red Hat® Enterprise Linux® 5.8; Red Hat Enterprise Linux 6.5; SUSE® Linux Enterprise Server 10 SP4; SUSE Linux Enterprise Server 11 SP3.

Virtualization Options: VMware® ESXi 5.1; VMware 6.0.
