| Product Overview |
|---|
The Cisco Catalyst 3650 24-Port switch is a versatile network device designed to deliver both connectivity and power to network endpoints while handling Layer 3 routing tasks. It fits well in office and data center racks, providing a balance of performance and manageability for mid-sized enterprise networks. |
| General Information | |
|---|---|
| Brand | Cisco |
| Part Number | WS-C3650-24PDM-L |
| Condition | Refurbished |
| Technical Information | |
|---|---|
| Switch Ports | 24 |
| Number of Ports | 24-Ports |
| Port Type | 10/100/1000Base-T, SFP+ |
| Port Speed | 10/100/1000Base-T |
| UpLink Ports | 2 x SFP+ (10G) |
| POE Support | PoE+ |
| Switching Capacity | 176 Gbps |
| Switch Forwarding Rate | 95.2 Mpps |
| DRAM | 4 GB |
| Flash Memory | 2 GB |
| VLAN Support | Yes |
| Max VLANs Supported | 1-4094 |
| Stackable | Yes |
| Layer Support | Layer 3 |
| Connector Type | RJ-45,SFP+ |
| Performance | |
|---|---|
| Jumbo Frame Support | Up To 9216 Bytes |
| MAC Address Table Size | 16000 |
| Management and Configuration | |
|---|---|
| Routing Protocols | Static, RIP, OSPF, OSPFv3, EIGRP, BGP, VRRP, HSRP, PIM-SM, IGMP |
| Remote Protocols | Yes |
| Security | Yes |
| Remote Management Protocol | SSH, Telnet, HTTP, HTTPS, SNMPv1/v2/v3, NETCONF, RESTCONF |
| Routing Protocol | Static, RIP, OSPF, EIGRP, BGP, VRRP, HSRP, PIM-SM, IGMP |
| Power & Cooling | |
|---|---|
| Fans | 2 field-replaceable fans |
| Power | AC 100-240V, 50-60Hz; PoE budget 370W |
| Physical Characteristics | |
|---|---|
| Dimensions | 1.73 x 17.5 x 18.0 in (H x W x D) |
| Weight | 10.00 |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Miscellaneous | |
|---|---|
| Eco Friendly | Yes |
| Compliance Standards | WEEE, RoHS, cURus, CE, FCC, UL, TUV, cULus |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1X, IEEE 802.3ad, IEEE 802.3az |
| Product Description |
|---|
The Cisco Catalyst 3650 24-Port switch delivers a robust solution for enterprise networking needs. Often found in medium to large office setups, it combines fast Ethernet access with Power over Ethernet Plus support, allowing both connectivity and power supply to devices like IP phones and wireless access points. Built for network administrators who require reliable, manageable hardware, this switch supports Layer 3 routing, facilitating efficient traffic management within complex network environments. Its 2 SFP+ ports provide enhanced uplink speeds, making it a versatile choice for expanding network infrastructure. Key Features
This switch is typically deployed in enterprise wiring closets or data center environments where dependable power and data transmission are critical. It helps streamline network operations by consolidating switching and routing tasks within a single device. |
