| Product Overview |
|---|
The Cisco Meraki MS350-48FP is a versatile Gigabit switch that combines high port density with Power over Ethernet capabilities. It fits into mid to large-scale networks requiring efficient device powering and flexible routing options, all managed through an intuitive cloud platform. |
| General Information | |
|---|---|
| Brand | Cisco Meraki |
| Part Number | MS350-48FP-HW |
| Condition | Refurbished |
| Technical Information | |
|---|---|
| Switch Ports | MS350-48FP-HW - 48 x RJ-45 PoE+ 10/100/1000Base-T |
| Number of Ports | 48-Ports |
| Port Type | 10/100/1000Base-T, SFP+, USB Console |
| Port Speed | 10/100/1000 Mbps |
| UpLink Ports | 4 x SFP+ (10G) uplinks, 2 x dedicated stacking ports (SFP+) |
| POE Support | PoE+ |
| Switching Capacity | 176 Gbps |
| Switch Forwarding Rate | 343.75 Mpps (64-byte) |
| VLAN Support | Yes |
| Max VLANs Supported | 4094 |
| Stackable | Yes |
| Layer Support | Layer 3 |
| Connector Type | RJ-45,SFP+,USB Console |
| Performance | |
|---|---|
| Jumbo Frame Support | Up To 9216 Bytes |
| Management and Configuration | |
|---|---|
| Routing Protocols | Static, OSPF, VRRP |
| Management Interfaces | Meraki Dashboard (Web), REST API, SNMP, Syslog, Mobile app |
| Security Features | 802.1X, RADIUS authentication, Access Control Lists (ACLs), Port security, DHCP Snooping, Storm control |
| Remote Management Protocol | HTTPS (SSL), SNMPv2c/v3, REST API, Syslog |
| Routing Protocol | Static, OSPF |
| Power & Cooling | |
|---|---|
| Power | 740W PoE budget; AC input 100-240VAC |
| Physical Characteristics | |
|---|---|
| Dimensions | 1.72 x 17.5 x 16.5 in (43.7 x 444 x 420 mm) |
| Weight | 3.00 |
| Operating Temperature | 0°C to 40°C |
| Miscellaneous | |
|---|---|
| Eco Friendly | Yes |
| Compliance Standards | WEEE, RoHS, CE, FCC, UL, TUV, cULus |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.1Q, IEEE 802.1p, IEEE 802.1X, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az |
| Product Description |
|---|
The Cisco Meraki MS350-48FP is a 48-port Gigabit Ethernet switch designed to deliver both data connectivity and power over Ethernet to devices such as IP phones, wireless access points, and security cameras. It's often found in enterprise or campus network environments where centralized management and reliable performance are critical. Built with a focus on scalability and simplified network administration, it benefits IT teams that require a switch capable of handling high-density connections along with seamless integration into cloud-based management platforms. Key Features
This switch is commonly deployed in offices, schools, and data centers where dense device connectivity and power delivery are essential. It streamlines network infrastructure by combining switching and power delivery, reducing the need for additional hardware and simplifying cable management. Its role in modern networks is to provide reliable, scalable, and manageable connectivity that supports both existing and future device needs without adding complexity for administrators. |
