| Product Overview |
|---|
The Cisco Catalyst IE-3200-8T2S-E is a rugged Layer 3 managed switch delivering eight gigabit copper ports and two SFP fiber slots. It fits into industrial networks requiring reliable high-speed connections and advanced routing in physically demanding environments. |
| General Information | |
|---|---|
| Brand | Cisco |
| Part Number | IE-3200-8T2S-E |
| Condition | Refurbished |
| Technical Information | |
|---|---|
| Switch Ports | 8 |
| Number of Ports | 10-Ports |
| Port Type | 10/100/1000Base-T, SFP |
| Port Speed | 10/100/1000Base-T |
| UpLink Ports | 2 |
| POE Support | No |
| Switching Capacity | 20 Gbps |
| Switch Forwarding Rate | 29.76 Mpps |
| VLAN Support | Yes |
| Max VLANs Supported | 1-4094 |
| Stackable | No |
| Layer Support | Layer 3 |
| Connector Type | RJ-45,SFP |
| Performance | |
|---|---|
| Jumbo Frame Support | Up To 9216 Bytes |
| MAC Address Table Size | 8192 |
| Management and Configuration | |
|---|---|
| Routing Protocols | Static, RIP, OSPF |
| Remote Protocols | Yes |
| Management Interfaces | CLI (Console/SSH/Telnet), Web UI (HTTP/HTTPS), SNMP, RMON |
| Security | Yes |
| Remote Management Protocol | SSH, Telnet, SNMPv2/v3, HTTP, HTTPS |
| Routing Protocol | Static, RIP, OSPF |
| Power & Cooling | |
|---|---|
| Fans | Fanless |
| Power | 12-48 VDC (dual redundant inputs supported) |
| Physical Characteristics | |
|---|---|
| Weight | 5.00 |
| Operating Temperature | -40 to 75 C |
| Miscellaneous | |
|---|---|
| Compliance Standards | WEEE, RoHS, CE, FCC, UL, TUV, cULus |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1D, IEEE 802.1w, IEEE 802.1X |
| Product Description |
|---|
The Cisco Catalyst IE-3200-8T2S-E is a compact industrial Ethernet switch designed to deliver reliable gigabit connectivity in challenging settings. It is often found in manufacturing plants, transportation networks, and outdoor installations where robust performance is critical. This switch is built for network engineers and system integrators who require advanced Layer 3 features combined with physical durability. Its rugged casing and temperature tolerance make it suitable for environments that standard IT gear can't handle. Key Features
Typically deployed in industrial automation, power distribution, and transportation systems, the IE-3200-8T2S-E ensures continuous network uptime. Its resilience helps maintain communication integrity where failure could disrupt critical operations. |
