IE-3300-8P2S-E Cisco Industrial Ethernet 3300 Series IE-3300-8P 8 x Ports PoE+ 10/100/1000Base-T + 2 x SFP Ports Layer 3 Managed DIN Rail Mountable Gigabit Ethernet Network Switch

SKU:
IE-3300-8P2S-E
Weight: 4.00 lbs
Condition: Refurbished
  • Compact industrial Layer 3 switch with 8 PoE+ RJ‑45 and 2 SFP ports
  • DIN‑rail mountable, fanless design for rugged environments
  • 360 W PoE budget supporting IEEE 802.3af/at on all copper ports
  • Line‑rate forwarding with advanced routing (OSPF, BGP, RIP, EIGRP, IS‑IS*)
In stock

$7,999.00

Product Overview

The IE‑3300‑8P2S‑E Cisco Catalyst IE3300 Rugged Series switch packs eight PoE+ copper ports and two SFP uplinks in a compact, fanless DIN‑rail chassis—delivering enterprise‑grade Layer 3 routing, secure management, and 360 W PoE power in harsh industrial settings.

General Information

Brand Cisco
Part Number IE-3300-8P2S-E
Condition Refurbished

Technical Information

Switch Type Managed Switch, Industrial Switch
Form Factor Compact
Mount Type DIN Rail
Number of Ports 10-Ports
Port Type 10/100/1000Base-T, SFP
Port Speed 1 Gbps copper; 1 Gbps fiber uplinks
UpLink Ports 2 × SFP (1 Gbps)
POE Support PoE+
Switching Capacity 20 Gbps
Switch Forwarding Rate 14.88 Mpps
DRAM 2 GB
Flash Memory 1.5 GB flash
Max VLANs Supported Supports up to 4,096 VLAN IDs
Layer Support Layer 2, Layer 3
Connector Type RJ-45 for Ethernet Ports, SFP for Uplink Ports

Performance

Jumbo Frame Support Up To 9000 Bytes
MAC Address Table Size 8K Entries

Management and Configuration

Routing Protocols Static, RIP, OSPF, EIGRP, BGP, IS-IS
Remote Protocols Cisco DNA Center, Catalyst Center, Industrial Network Director, WebUI, CLI
Management Interfaces WebUI, SNMP v2/3, SSH, RESTCONF, NETCONF
Security Features Secure boot, AAA, 802.1X, ACLs, MACsec* (Adv license), DHCP/ARP snooping

Power & Cooling

Fans Fanless (silent)

Physical Characteristics

Dimensions 15.2 × 9.1 × 13.5 cm
Weight 4.00

Miscellaneous

Eco Friendly Yes
Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1X, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt


Product Description

The IE‑3300‑8P2S‑E is a rugged, fanless industrial switch offering 8 PoE/PoE+ copper ports plus 2 gigabit SFP uplinks, designed for compact deployment on DIN‑rail or wall mounts in harsh environments.

Key Features

  • 8 × 10/100/1000 RJ‑45 PoE+ ports with up to 360 W total budget
  • 2 × 100/1000 SFP uplinks for flexible fiber connectivity
  • Layer 2 & Layer 3 routing with protocols like OSPF, BGP, RIP, EIGRP, IS‑IS*
  • Fanless, IP30‑rated design for reliability in extreme conditions
  • Secure management via SNMP v2/3, SSH, RESTCONF, NETCONF, plus MACsec* and 802.1X

Ideal for industrial IoT, security cameras, or remote site networks needing reliable PoE delivery and robust routing. Its fanless, rugged build and redundant DC support make it perfect for energy‑constrained or outdoor cabinets.


Use Cases

The IE-3300-8P2S-E Cisco Industrial Ethernet 3300 Series switch is engineered for rigorous industrial environments where reliable, secure, and scalable network connectivity is essential. It suits operations requiring robust Layer 3 routing and high PoE power delivery in settings such as manufacturing plants, transportation hubs, and energy grids, supporting users that manage complex, real-time data flows and IoT device integration.

How It's Used:

  • Deploying in manufacturing automation networks to connect and power IP cameras, sensors, and control systems with stringent uptime requirements.
  • Integrating into transportation infrastructure for seamless data exchange between signaling components and operational control centers.
  • Supporting energy sector facilities with ruggedized connectivity for SCADA systems and distributed telemetry devices in harsh conditions.
  • Facilitating edge computing nodes in remote industrial sites by enabling secure Layer 3 routing and redundant uplinks for data aggregation.
  • Enabling smart building applications where consolidated PoE power and managed switching simplify network architecture for multiple device types.

This switch enhances operational efficiency by providing deterministic network performance and resilient routing capabilities, allowing industrial networks to scale effectively while maintaining high availability under challenging environmental factors.
