Name: CBS220-48FP-4X Cisco 48-Port PoE+ Gigabit Switch 4x 10Gbps SFP+ Layer 2
Brand: Cisco
SKU: CBS220-48FP-4X
Price: 2200.00 USD
Availability: InStock
Rating: 4.8 (119 reviews)

Product Overview
The Cisco Business 220 Series CBS220-48FP-4X combines 48 PoE+ Gigabit ports and four 10Gbps SFP+ uplinks into a single rack-mountable switch. It fits well in business networks aiming to power various devices over Ethernet while managing traffic efficiently at Layer 2. This switch is a practical choice for offices that require a balance of speed, power delivery, and manageability without complexity.

General Information
Brand	Cisco
Part Number	CBS220-48FP-4X
Condition	Refurbished

Technical Information
Switch Ports	48
Number of Ports	48-Ports
Port Type	10/100/1000Base-T, 10G SFP+
Port Speed	10/100/1000 Mbps (copper), 10 Gbps (SFP+ uplinks)
UpLink Ports	4
POE Support	PoE+
Switching Capacity	176 Gbps
Switch Forwarding Rate	343.75 Mpps
VLAN Support	Yes
Max VLANs Supported	1-4094
Layer Support	Layer 2
Connector Type	RJ-45,SFP+

Performance
Jumbo Frame Support	Up To 9216 Bytes
MAC Address Table Size	16000

Management and Configuration
Remote Protocols	Yes
Management Interfaces	Web GUI (HTTPS), Command Line Interface (CLI), SNMP, SSH, Telnet, Console
Remote Management Protocol	SNMPv1/v2c/v3, SSH, Telnet, HTTP/HTTPS

Power & Cooling
Power	740W PoE budget

Physical Characteristics
Weight	5.00

Miscellaneous
Compliance Standards	WEEE, RoHS, CE, FCC, UL, cULus
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3at

Product Description
The Cisco Business 220 Series CBS220-48FP-4X is a versatile managed Ethernet switch designed to support growing business networks. It offers robust Power over Ethernet (PoE+) capabilities, allowing it to power devices such as IP phones, wireless access points, and security cameras directly through the network cable. Often found in small to medium-sized office networks, this switch provides reliable data transfer speeds and flexible network management. Network administrators benefit from its intuitive management features and the ability to handle high-bandwidth applications. Key Features PoE+ functionality delivers up to 30W per port to power connected devices without extra cabling Four 10Gbps SFP+ uplinks ensure fast and stable connections to core networks or servers Layer 2 management supports VLANs, QoS, and security features for improved network performance Rack-mountable design fits standard 19-inch racks in data closets or wiring cabinets Energy-efficient technology helps reduce power consumption during low traffic periods This switch is typically deployed in office environments where multiple PoE devices need centralized power and network access. It plays a key role in maintaining consistent network speeds while simplifying infrastructure by combining power and data delivery.

Use Cases
The Cisco CBS220-48FP-4X switch is ideal for medium to large business networks that require reliable Power over Ethernet to support devices like IP phones, wireless access points, and security cameras. It is best suited for IT environments demanding high uplink speeds and centralized management without the complexity of full Layer 3 configurations. How It's Used: Deploying in campus networks to power and connect VoIP phones and wireless access points across multiple floors. Supporting surveillance systems in retail or corporate environments with PoE-powered IP cameras. Integrating into SMB data closets to aggregate wired connections and provide 10Gbps uplinks to core switches. Facilitating edge computing setups where low-latency switching and power provision are essential. Providing a managed Layer 2 network foundation for remote office or branch office connectivity. This switch enhances operational efficiency by combining power delivery and high-bandwidth uplinks within a manageable Layer 2 architecture. Its rack-mount design and PoE+ capabilities enable scalable deployments that accommodate growing device density and bandwidth demands.
