| Product Overview |
|---|
The Cisco Catalyst 9200L-48T-4G-E-RF switch delivers a balanced mix of high port count and advanced Layer 3 capabilities. It's designed to manage complex network traffic in business settings, fitting well as a main distribution or access layer switch. Its combination of Gigabit Ethernet ports and 10Gbps uplinks makes it a versatile choice for networks that require both speed and reliability without unnecessary complexity. |
| General Information | |
|---|---|
| Brand | Cisco |
| Part Number | C9200L-48T-4G-E-RF |
| Condition | Refurbished |
| Technical Information | |
|---|---|
| Switch Ports | 48 |
| Number of Ports | 48-Ports |
| Port Speed | 10/100/1000Base-T, 10G SFP+ uplinks |
| Switching Capacity | 176 Gbps |
| Switch Forwarding Rate | 130.95 Mpps |
| DRAM | 4 GB |
| Flash Memory | 4 GB |
| Max VLANs Supported | 1-4094 |
| Connector Type | RJ-45,SFP+ |
| Performance | |
|---|---|
| Jumbo Frame Support | Up To 9216 Bytes |
| MAC Address Table Size | 32,000 |
| Management and Configuration | |
|---|---|
| Remote Management Protocol | SSH, HTTPS, HTTP, SNMP, NETCONF, RESTCONF |
| Routing Protocol | OSPF,RIP,EIGRP,BGP |
| Power & Cooling | |
|---|---|
| Fans | 1 field-replaceable fan (variable-speed) |
| Power | AC 100-240V, 50-60Hz |
| Physical Characteristics | |
|---|---|
| Dimensions | 1.73 x 17.5 x 16.8 in (4.4 x 44.5 x 42.7 cm) |
| Weight | 3.00 |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Miscellaneous | |
|---|---|
| Compliance Standards | WEEE, RoHS, cURus, CE, FCC, UL, TUV |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ae, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1X |
| Product Description |
|---|
The Cisco Catalyst 9200L-48T-4G-E-RF is a robust network switch designed to handle demanding enterprise network traffic with ease. It often appears in office networks and data centers, where dependable and scalable wired connections are essential. This switch is built for IT professionals and network administrators who require a stable, managed solution to support multiple devices and applications. Key Features
This switch typically finds its place in mid-sized to large enterprise networks and campus environments where performance and reliability are key. By providing strong connectivity options and routing features, it helps maintain smooth data flow and keeps networks running without interruptions. |
