| Product Overview |
|---|
The Cisco Catalyst C1000-16FP-2G-L is a managed gigabit switch designed to provide reliable power and data connectivity for mid-sized networks. It fits well in environments that need straightforward management and PoE support, like small offices or retail locations, offering a balance of performance and essential features without unnecessary complexity. |
| General Information | |
|---|---|
| Brand | Cisco |
| Part Number | C1000-16FP-2G-L |
| Condition | Refurbished |
| Technical Information | |
|---|---|
| Form Factor | Rack-Mountable |
| Mount Type | 1U Rack |
| Switch Ports |
16 x 10/100 PoE+ RJ45 ports 2 x 1G SFP uplink ports |
| Number of Ports | 16-Ports |
| Port Type | 10/100/1000Base-T, SFP |
| Port Speed |
10/100 Mbps (PoE+ ports) 1 Gbps (SFP uplinks) |
| UpLink Ports | 2 (SFP) |
| POE Support | PoE+ |
| Switching Capacity | 8.8 Gbps |
| Switch Forwarding Rate | 6.5 Mpps |
| DRAM | 512 MB |
| Flash Memory | 256 MB |
| VLAN Support | Yes |
| Max VLANs Supported | 1-4094 |
| Stackable | No |
| Layer Support | Layer 2 |
| Connector Type | RJ-45,SFP |
| Performance | |
|---|---|
| Latency | <5 μs (typical) |
| Jumbo Frame Support | Up To 9000 Bytes |
| MAC Address Table Size | 8,000 entries |
| Management and Configuration | |
|---|---|
| Remote Protocols | Yes |
| Management Interfaces | Web UI (HTTP/HTTPS), CLI (Console, SSH), SNMP, RMON, Syslog |
| Management Type | Fully Managed (Cisco IOS Software, CLI, Web UI) |
| Security | 802.1X, Port Security, DHCP Snooping, TACACS+/RADIUS, SSH/SSL |
| Remote Management Protocol | SSH,HTTPS,SNMP,CLI |
| Routing Protocol | VLAN, QoS, ACLs, SNMP, LLDP, IGMP Snooping, Static Routing |
| Power & Cooling | |
|---|---|
| Power |
PoE+ (802.3at) Total PoE Budget: 195W |
| Power Supply | Internal fixed (100-240V AC) |
| Physical Characteristics | |
|---|---|
| Weight | 5.00 |
| Operating Temperature | 32 to 104 F (0 to 40 C) |
| Miscellaneous | |
|---|---|
| Compliance Standards | WEEE, RoHS, CE, FCC, UL, TUV, cULus |
| Compliant Standards | IEEE 802.3,IEEE 802.3u,IEEE 802.3ab,IEEE 802.3z,IEEE 802.1Q,IEEE 802.1p,IEEE 802.1D,IEEE 802.1w,IEEE 802.1s,IEEE 802.1X,IEEE 802.3af,IEEE 802.3at,IEEE 802.3x |
| Product Description |
|---|
The Cisco Catalyst C1000-16FP-2G-L is a Layer 2 managed switch built for small to medium business networks that require robust Power over Ethernet capabilities. It is commonly used in office environments, retail spaces, or branch locations where devices like IP phones, wireless access points, and cameras need both power and data through a single cable. Network administrators and IT teams often find this switch practical for simplifying network setups without sacrificing control features such as VLAN segmentation and traffic prioritization. It supports essential management functions, enabling easy integration into existing networks. Key Features
This switch is typically deployed in small business networks where space and power delivery are important. It helps reduce cable clutter by combining power and networking, making it a straightforward choice for powering and connecting a variety of network devices. Its managed capabilities give users control over their network's traffic and security without the complexity of higher-end switches. |
