| Product Overview |
|---|
The B-EX4600-40FO-EDU combines 24 SFP+ ports at 10Gbps with 4 QSFP+ uplinks delivering 40Gbps capacity, fitting well within enterprise or campus networking setups. It manages traffic efficiently and supports both Layer 2 and Layer 3 protocols, making it adaptable to different network designs and requirements. |
| General Information | |
|---|---|
| Brand | Juniper Networks |
| Condition | Refurbished |
| Technical Information | |
|---|---|
| Switch Type | Layer 2, Layer 3, Managed Switch, Stackable Switch |
| Form Factor | Rack-Mountable |
| Mount Type | 1U Rack |
| Switch Ports | 24 |
| Number of Ports | 24-Ports |
| Port Type | SFP+, QSFP / QSFP+, USB Console, Serial Console (RJ-45) |
| Port Speed | 10Gbps,40Gbps |
| UpLink Ports | 4 x 40Gbps QSFP+ |
| POE Support | No |
| VLAN Support | Yes |
| Max VLANs Supported | 1-4094 |
| Stackable | Yes |
| Layer Support | Layer 2, Layer 3 |
| Connector Type | SFP+,QSFP+,Serial Console (RJ-45),USB Console |
| Performance | |
|---|---|
| Jumbo Frame Support | Up To 9216 Bytes |
| MAC Address Table Size | 32000 |
| Management and Configuration | |
|---|---|
| Routing Protocols | Static, RIP, OSPF, BGP, VRRP, PIM-SM, IGMP |
| Remote Protocols | Yes |
| Management Interfaces | Web UI (J-Web),CLI (Junos),SSH,SNMP,Console (RJ-45),USB |
| Security Features | 802.1X,ACLs,Port security,Storm control |
| Management Type | Managed |
| Remote Management Protocol | SSH,HTTPS,Telnet (optional),SNMPv1/v2c/v3 |
| Routing Protocol | Static,RIP,OSPF,BGP,VRRP,PIM-SM,IGMP |
| Physical Characteristics | |
|---|---|
| Weight | 3.00 |
| Operating Temperature | 0°C to 45°C (32°F to 113°F) |
| Miscellaneous | |
|---|---|
| Assembly Required | No |
| Product Description |
|---|
The B-EX4600-40FO-EDU is a network switch designed to deliver high-performance connectivity with a combination of SFP+ and QSFP+ ports, suited for environments that require scalable 10Gbps and 40Gbps Ethernet connections. Often found in enterprise and educational institutions' network cores or distribution layers, this switch balances port density with flexible uplink options. Built for network engineers and IT administrators managing mid-sized to large-scale campus or data center networks, it facilitates efficient traffic handling and network segmentation. The device's compact rack-compatible design supports streamlined infrastructure deployment without compromising performance. Key Features
With its combination of speed and port variety, this switch plays an important role in maintaining smooth data flow and network responsiveness. Its reliability and performance make it a practical choice for organizations requiring stable and scalable network infrastructure. |
| Use Cases |
|---|
This switch is typically deployed in network cores or distribution layers within enterprise campuses, educational networks, and data centers where high throughput and reliable connectivity are essential. Network professionals rely on it to handle substantial data loads and aggregation tasks with low latency. How It's Used:
In these scenarios, the switch contributes to improved operational efficiency and network scalability, supporting evolving demands without compromising performance or stability. |
