Name: AT-GS980MX/10HSM-10 Allied Telesis 8x5Gbps PoE+ 2x10Gbps SFP+ Layer 3 Switch
Brand: Allied Telesis
SKU: AT-GS980MX/10HSM-10
Price: 1294.00 USD
Availability: InStock
Rating: 4.8 (118 reviews)

Product Overview
The Allied Telesis CentreCOM GS980MX Series switch combines multi-gigabit PoE+ ports with 10Gbps uplinks and Layer 3 management to handle demanding network environments. It fits well in business or campus networks where reliable, high-speed connections and flexible uplink options are essential for smooth data flow and device power supply.

General Information
Brand	Allied Telesis
Part Number	AT-GS980MX/10HSM-10
Condition	Refurbished

Technical Information
Switch Type	Managed Switch
Form Factor	Rack-Mountable
Mount Type	1U Rack
Switch Ports	No
Number of Ports	8-Ports
Port Type	5GBase-T, RJ-45, SFP+
Port Speed	Multi-Gigabit (0.1, 1, 2.5, 5 Gbps) + 10 Gbps uplinks
UpLink Ports	2 x 10G SFP+
POE Support	PoE++
Switching Capacity	120 Gbps
Switch Forwarding Rate	89.2 Mpps
DRAM	1 GB
Flash Memory	256 MB
VLAN Support	Yes
Max VLANs Supported	Up to 4094 VLANs
Stackable	No
Layer Support	Layer 3
Connector Type	RJ‑45, SFP

Performance
Jumbo Frame Support	Up To 9216 Bytes
MAC Address Table Size	16,000 entries

Management and Configuration
Routing Protocols	Static, RIP, IGMP
Remote Protocols	SNMPv1/v2c/v3, Telnet, SSH, HTTP/HTTPS, CLI
Management Interfaces	Web GUI, CLI (Console, SSH), SNMP (v1/v2c/v3), RMON, HTTP/HTTPS, Telnet
Security Features	ACLs, 802.1x, MAC filtering, DAI, RADIUS, SSH, SSL/TLS, etc.
Security	802.1X, ACLs, MAC filtering, DHCP Snooping, IP Source Guard, Port Security
Remote Management Protocol	SNMPv1/v2c/v3, SSH, HTTPS, Telnet, RMON
Routing Protocol	Static Routing, RIP

Power & Cooling
Power	AC 100-240V, 50/60Hz; PoE budget 240W

Physical Characteristics
Dimensions	4.25 x 21 x 36.2 cm
Weight	4.00
Operating Temperature	0°C to 40°C

Miscellaneous
Compliance Standards	WEEE, RoHS, CE, FCC, cULus
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3bz, IEEE 802.3ae, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1X, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x

Product Description
The Allied Telesis CentreCOM GS980MX Series switch provides a powerful combination of 5Gbps PoE+ ports and 10Gbps uplinks to handle demanding network environments. Built for use in enterprise or campus networks, it enables high-speed data transfer and efficient power delivery to devices like access points and IP cameras. Often found in workplaces and data centers, this Layer 3 switch offers advanced features such as routing capabilities and traffic prioritization, making it a solid choice for IT professionals managing complex network traffic. Key Features Eight 5Gbps PoE+ ports deliver both power and high-speed connectivity to network devices Two 10Gbps SFP+ ports allow flexible uplink options including fiber for long-distance connections Layer 3 management supports routing protocols to optimize data flow across networks Robust traffic control features help maintain network performance under heavy loads Compact design suits both rack and desktop deployment in varied environments This switch is typically deployed in office networks, education campuses, or any setting where multiple high-speed connections and power over Ethernet are needed. It plays a key role in supporting network infrastructure while simplifying device management.

Use Cases
The Allied Telesis AT-GS980MX/10HSM-10 switch is primarily deployed in midsize to large enterprise and campus networks that require high-speed, reliable connectivity with power delivery for edge devices. It benefits IT teams managing environments where multi-gigabit device connections and scalable uplinks are critical for handling intensive data traffic and diverse workloads. How It's Used: Connecting high-density wireless access points in corporate campuses to support bandwidth-intensive applications and seamless roaming. Aggregating traffic from multiple office floors in enterprise buildings to centralize management and optimize network performance. Providing PoE+ power and multi-gigabit data rates for IP telephony and video conferencing endpoints in professional office environments. Enabling edge computing deployments where ruggedized, high-throughput switching is needed near IoT and sensor networks. Supporting virtualization environments by delivering high-speed uplinks to servers in data center aggregation layers. Integrating fiber and copper connectivity in hybrid network architectures for education campuses requiring flexible uplink options. This switch enhances operational efficiency by consolidating power and data delivery in a single platform while facilitating scalability through its combination of multi-gigabit PoE+ ports and 10Gbps uplinks. Its Layer 3 capabilities support advanced routing which is essential for maintaining performance and reliability in dynamic, multi-segment network infrastructures.
