Name: AL7000S2F-E6 Avaya Virtual Services Platform 7024XT 24-Port Ethernet Switch
Brand: Avaya
SKU: AL7000S2F-E6
Price: 3835.00 USD
Availability: InStock
Rating: 4.8 (118 reviews)

Product Overview
The Avaya Virtual Services Platform 7024XT is a 24-port Ethernet switch designed to deliver reliable, high-speed connectivity within enterprise networks. It fits well in data centers or large campus environments where both Layer 2 and Layer 3 functionalities are essential for managing complex network traffic.

General Information
Brand	Avaya
Part Number	AL7000S2F-E6
Condition	Refurbished

Technical Information
Form Factor	Rack-Mountable
Mount Type	1U Rack
Switch Ports	24 x 10/100/1000Base-T (RJ-45), 2 x 10Gb SFP+ uplink
Number of Ports	24-Ports
Port Type	10GBase-T
Port Speed	10 Gbps
UpLink Ports	1 MDA Slot (supports 8x10G SFP+ or 8x10GBASE-T or 2x40G or 1x100G)
POE Support	No
Switching Capacity	1.28 Tbps
Switch Forwarding Rate	960 Mpps
VLAN Support	Yes
Max VLANs Supported	1-4094
Layer Support	Layer 2, Layer 3
Connector Type	RJ45, SFP+

Performance
Latency	500ns
Jumbo Frame Support	Up To 9216 Bytes
MAC Address Table Size	Up to 131,000 MAC entries

Management and Configuration
Routing Protocols	RIP, OSPF
Remote Protocols	Fabric Connect, CLI, SNMP v1/v2/v3, web
Management Interfaces	CLI (Console), Web GUI, SNMPv1/v2c/v3, SSH, Telnet
Security Features	VLAN, ACLs, VRRP, storm control, SLPP/SLPP Guard
Security	802.1X, RADIUS, TACACS+, ACLs, Port Security, DHCP Snooping
Remote Management Protocol	SNMPv1/v2c/v3, SSH, HTTPS, Telnet
Routing Protocol	Static Routing, OSPF, RIP, VRRP

Physical Characteristics
Dimensions	1.75 x 19 x 16 inches
Weight	4.00
Operating Temperature	0°C to 40°C (32°F to 104°F)

Miscellaneous
Compliance Standards	RoHS, CE, FCC, UL, cULus
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1X

Product Description
The Avaya Virtual Services Platform 7024XT is a compact, high-capacity Ethernet switch designed to handle robust network traffic in enterprise environments. Often found in data centers or network aggregation points, it delivers reliable connectivity and advanced network services. Built for IT professionals managing complex LANs, this switch supports virtualized network functions and offers flexible configuration options to meet varying business needs. Key Features Offers 24 Gigabit Ethernet ports plus multiple 10GbE uplink ports Supports both Layer 2 switching and Layer 3 routing capabilities Integrates seamlessly with Avaya's Virtual Services Platform architecture Provides low latency and high throughput for demanding applications Includes enhanced security features to protect network integrity Typically deployed in enterprise campus networks or data centers, this switch plays a critical role in ensuring fast and stable connectivity. It helps IT teams efficiently manage traffic loads while supporting virtualization and network segmentation.

Use Cases
The Avaya Virtual Services Platform 7024XT is primarily deployed in enterprise network environments requiring high throughput and resilient connectivity. IT teams managing data centers or large campus networks utilize this switch to support diverse applications ranging from virtualization to complex routing tasks. How It's Used: Integrating core switching within university campus networks to handle high-density user traffic and secure segmentation. Supporting virtualization clusters in data centers by providing low-latency connectivity for storage and server access. Enabling edge computing deployments in distributed enterprise branches requiring scalable Layer 2 and Layer 3 networking. Facilitating aggregation in large corporate LANs where mixed 1GbE and 10GbE throughput is critical for performance-intensive workloads. Deploying in communication service provider environments for reliable Ethernet services with advanced traffic management capabilities. This switch enhances operational efficiency by delivering consistent low-latency switching and integrated Layer 3 routing, allowing enterprises to scale network capacity without compromising performance. Its compatibility with virtual services platforms ensures seamless integration into evolving network topologies.
