Name: 7165H1X Lenovo 12-Port PoE Ethernet Switch EX2300-C-12P Layer 2
Brand: Lenovo
SKU: 7165H1X
Price: 948.05 USD
Availability: InStock
Rating: 4.8 (119 reviews)

Product Overview
The Lenovo Juniper EX2300-C-12P is a compact Ethernet switch that offers essential network connectivity with built-in PoE functionality. It fits well in small office or branch environments where space is limited but powering devices through Ethernet is needed. The switch balances straightforward operation with enough features to support typical network setups without extra complexity.

General Information
Brand	Lenovo
Part Number	7165H1X
Condition	Refurbished

Technical Information
Form Factor	Rack-Mountable
Mount Type	1U Rack, Desktop
Switch Ports	Yes
Number of Ports	12-Ports
Port Type	10/100/1000Base-T, SFP, SFP+
Port Speed	1 GbE access, 10 GbE uplink
UpLink Ports	2× 1/10 GbE SFP+
POE Support	PoE+
Switching Capacity	64 Gbps
Switch Forwarding Rate	47 Mpps
VLAN Support	Yes
Max VLANs Supported	4,093 VLANs
Stackable	No
Layer Support	Layer 2, Layer 3
Connector Type	RJ-45 (ports, OOB mgmt), Mini-USB, USB, RJ-45 console

Performance
Jumbo Frame Support	Up To 9216 Bytes
MAC Address Table Size	16,000 entries

Management and Configuration
Routing Protocols	Static, RIP, OSPF, VRRP, IGMP
Remote Protocols	Junos OS, SNMP, CLI via console/SSH
Management Interfaces	1× RJ-45 Ethernet out-of-band, 1× RJ-45 console, 1× Mini-USB, 1× USB for uploads
Security Features	DHCP snooping, DAI, MAC limiting; 802.1X, LLDP‑MED; physical security slots
Management Type	Junos CLI, J-Web (web GUI), SNMP
Security	802.1X, ACLs, RADIUS authentication
Remote Management Protocol	SSH, HTTPS, HTTP, SNMP
Routing Protocol	Static routing, OSPF

Power & Cooling
Fans	No

Physical Characteristics
Weight	4.00
Operating Temperature	0°C to 40°C

Miscellaneous
Eco Friendly	Yes
Compliance Standards	RoHS, CE, FCC, UL
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1X, IEEE 802.3af, IEEE 802.3at

Product Description
The Lenovo Juniper EX2300-C-12P is designed to handle network demands in tight spaces while delivering robust connectivity. Often found in small offices or branch locations, this switch offers 12 PoE ports that power devices like IP phones, wireless access points, and cameras directly through Ethernet cables. Built for IT teams managing compact network setups, it enables straightforward deployment without the need for separate power adapters. Its Layer 2 switching capabilities, along with some Layer 3 features, provide the flexibility required for simple network segmentation and traffic management. Key Features Supports 12 PoE-enabled Ethernet ports with auto-sensing power delivery Compact form factor suited for limited rack or wall space Delivers basic Layer 3 routing to aid network traffic flow Energy-efficient design reduces power consumption during low usage periods Integrated Junos OS providing familiar network management tools Typically deployed in small business environments, branch offices, or classrooms, this switch serves well where space and power efficiency are priorities. It helps maintain straightforward network connectivity without adding complexity, making it easier for administrators to support day-to-day operations.

Use Cases
The Lenovo 7165H1X EX2300-C-12P Ethernet switch is ideal for compact network environments that require reliable PoE connectivity, such as branch offices and small business setups. It suits IT teams managing limited rack space while needing to power and connect multiple network devices efficiently. How It's Used: Deploying VoIP phones and IP cameras in small branch offices with centralized power delivery over Ethernet. Supporting wireless access points in SMB networks that require streamlined cabling and power management. Integrating network devices in retail locations where space constraints demand compact, energy-efficient switches. Enabling edge computing nodes in remote or distributed sites requiring basic Layer 2 switching and PoE support. Facilitating network segmentation and connectivity in small IT closets for remote office infrastructure. By consolidating power and data onto a single cable, this switch enhances operational efficiency and reduces infrastructure complexity in constrained environments. Its balance of Layer 2 switching with foundational routing capabilities supports scalable network growth without excessive overhead.
