| Product Overview |
|---|
The 4850GTS-PWR+ switch combines high port density with PoE+ power and integrated routing, making it a solid choice for networks needing both flexibility and efficiency. It fits well in situations where many devices need power and fast data connections, such as corporate campuses or large branch offices. Its uplink ports ensure smooth integration into broader network infrastructures without bottlenecks. |
| General Information | |
|---|---|
| Brand | Avaya |
| Part Number | 4850GTS-PWR+ |
| Condition | Refurbished |
| Alternate Part Number | 4850GTS-PWR+-06-CT |
| Technical Information | |
|---|---|
| Switch Ports | 48 |
| Number of Ports | 48-Ports |
| Port Type | 10/100/1000Base-T, 10G SFP+ |
| Port Speed | 10/100/1000 Mbps |
| UpLink Ports | 4 x 10G SFP+ |
| POE Support | PoE+ |
| Switching Capacity | 176 Gbps |
| Switch Forwarding Rate | 130.95 Mpps |
| DRAM | 512 MB |
| Flash Memory | 256 MB |
| VLAN Support | Yes |
| Max VLANs Supported | 1-4094 |
| Layer Support | Layer 3 |
| Connector Type | RJ-45,SFP+,USB Console,Serial Console (RJ-45) |
| Performance | |
|---|---|
| Jumbo Frame Support | Up To 9216 Bytes |
| MAC Address Table Size | 32000 |
| Management and Configuration | |
|---|---|
| Routing Protocols | Static, RIP, OSPF, OSPFv3, VRRP, PIM-SM, IGMP, MLD, Policy-Based Routing (PBR), Route Maps |
| Remote Protocols | Yes |
| Management Interfaces | CLI (Console/SSH/Telnet), Web GUI (HTTP/HTTPS), SNMPv1/v2c/v3, RMON |
| Security Features | 802.1X, RADIUS, TACACS+, ACLs, SSH, SSL, Port Security, BPDU Guard, Storm Control, DoS Prevention |
| Management Type | CLI, Web GUI, SNMP, Out-of-band Console |
| Remote Management Protocol | SNMPv1/v2c/v3, SSH, HTTPS, Telnet, RMON, HTTP |
| Routing Protocol | Static,RIP,OSPF,VRRP |
| Power & Cooling | |
|---|---|
| Fans | 2 (hot-swappable, redundant) |
| Power | AC 100-240V, 50/60 Hz; PoE budget up to 1440W (system) |
| Power Supply | Dual hot-swappable AC power supplies (field-replaceable) |
| Physical Characteristics | |
|---|---|
| Weight | 3.00 |
| Operating Temperature | 0°C to 40°C |
| Miscellaneous | |
|---|---|
| Compliance Standards | WEEE, RoHS, CE, FCC, UL, TUV, cULus |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1D, IEEE 802.1s, IEEE 802.3x, IEEE 802.1X |
| Product Description |
|---|
The 4850GTS-PWR+ is a high-performance Ethernet routing switch designed to handle demanding network environments. Often found in enterprise and campus networks, it provides reliable Gigabit connectivity along with Power over Ethernet Plus (PoE+) to power devices like IP phones, cameras, and wireless access points directly through the network cable. Built for IT professionals managing medium to large networks, this switch simplifies infrastructure by combining routing functions with high port density and flexible uplink options. Its PoE+ support means fewer power adapters and a cleaner setup for powered devices. Key Features
This switch is typically deployed in office buildings, schools, or data centers where numerous powered devices require both network access and electrical power. By consolidating routing and switching in one unit, it eases network management and enhances performance in busy network environments. |
| Use Cases |
|---|
The 4850GTS-PWR+ is ideal for organizations seeking to consolidate power and data infrastructure while maintaining high-speed network performance. How It's Used:
Its ability to deliver both data and power efficiently makes it a versatile solution for modern network deployments requiring reliable and scalable connectivity. |
