| Product Overview |
|---|
The Mellanox AS4610-54T integrates 48 Gigabit Ethernet ports with 4 10G SFP+ uplinks, providing a solid foundation for wired networks in data centers and enterprise environments. It handles traffic management and network segmentation effectively, fitting into setups that demand both performance and manageable control. |
| General Information | |
|---|---|
| Brand | Mellanox |
| Part Number | 4610-54T-O-AC-B |
| Condition | Refurbished |
| Technical Information | |
|---|---|
| Switch Ports | 48 |
| Number of Ports | 48-Ports |
| Port Type | 10/100/1000Base-T, SFP+ |
| Port Speed | 10/100/1000Base-T |
| UpLink Ports | 4 x 10G SFP+ |
| POE Support | No |
| Switching Capacity | 176 Gbps |
| Switch Forwarding Rate | 176 Gbps (non-blocking switching capacity) |
| DRAM | 1 GB DDR3 |
| Flash Memory | 128 MB |
| VLAN Support | Yes |
| Max VLANs Supported | 1-4094 |
| Stackable | No |
| Layer Support | Layer 3 |
| Connector Type | RJ-45,SFP+ |
| Performance | |
|---|---|
| Latency | <2 µs (line-rate, cut-through) |
| Jumbo Frame Support | Up To 9216 Bytes |
| MAC Address Table Size | 32768 |
| Management and Configuration | |
|---|---|
| Routing Protocols | Static, RIP, OSPF, BGP, VRRP, HSRP, PIM-SM, IGMP |
| Remote Protocols | Yes |
| Management Interfaces | CLI (SSH),SNMP,RMON,Web GUI |
| Security Features | SSH,ACL,802.1X,RADIUS,TACACS+ |
| Security | 802.1X, ACLs, RADIUS, TACACS+, port security |
| Remote Management Protocol | SNMPv1/v2/v3,SSH,HTTP/HTTPS |
| Routing Protocol | Layer 2/Layer 3: static routing, RIP, OSPF, BGP (via Mellanox/Onyx/MLNX-OS firmware) |
| Power & Cooling | |
|---|---|
| Fans | 2 hot-swappable fans |
| Power Supply | AC |
| Physical Characteristics | |
|---|---|
| Dimensions | 1.73 x 17.32 x 16.54 in (H x W x D) |
| Weight | 11.00 |
| Operating Temperature | 0°C to 40°C |
| Miscellaneous | |
|---|---|
| Eco Friendly | Yes |
| Assembly Required | Yes |
| Compliance Standards | RoHS, CE, FCC |
| Compliant Standards | IEEE 802.3,IEEE 802.3u,IEEE 802.3ab,IEEE 802.3z,IEEE 802.1Q,IEEE 802.1p,IEEE 802.1D,IEEE 802.1w |
| Product Description |
|---|
The Mellanox AS4610-54T is a managed network switch designed to handle high volumes of data across enterprise and data center networks. It combines 48 Gigabit Ethernet ports with 4 10G SFP+ slots, offering a versatile solution for connecting a wide range of devices including servers, storage units, and workstations. Often found in environments where network performance and management are critical, this switch is built for IT professionals who need granular control over traffic and security. Its managed capabilities allow for traffic shaping, VLAN segmentation, and real-time monitoring, making it suitable for medium to large network deployments. Key Features
This switch is typically deployed in corporate data centers, server rooms, and enterprise networks where dependable wired connections and network control are required. It facilitates efficient data handling while allowing IT teams to maintain network health and security without complexity. |
