| Product Overview |
|---|
The Dell PowerConnect 3524P 24-Ports PoE Network Switch delivers essential networking functions by combining data switching and power delivery over Ethernet. It fits into network environments where powering devices directly through network cables simplifies installation and reduces additional wiring requirements. Its design caters to organizations seeking a balance between performance and straightforward network management. |
| General Information | |
|---|---|
| Brand | Dell |
| Condition | Refurbished |
| Technical Information | |
|---|---|
| Switch Type | Layer 2, Managed Switch, Smart Managed Switch, PoE Switch |
| Form Factor | Rack-Mountable |
| Mount Type | 1U Rack |
| Switch Ports | 24 |
| Number of Ports | 24-Ports |
| Port Type | 10/100Base-T, 1000Base-T, Combo RJ-45/SFP, SFP, Serial Console (RJ-45) |
| Port Speed | 10/100 Mbps |
| UpLink Ports | 2 x Gigabit (combo RJ-45/SFP) |
| POE Support | PoE |
| Switching Capacity | 8.8 Gbps |
| Switch Forwarding Rate | 17.1875 Mpps |
| DRAM | 64 MB |
| Flash Memory | 16 MB |
| VLAN Support | Yes |
| Max VLANs Supported | 4094 |
| Stackable | No |
| Layer Support | Layer 2+ |
| Connector Type | RJ-45,SFP,Combo RJ-45/SFP,Serial Console (RJ-45) |
| Performance | |
|---|---|
| Jumbo Frame Support | Up To 9000 Bytes |
| MAC Address Table Size | 8192 |
| Management and Configuration | |
|---|---|
| Routing Protocols | Static |
| Remote Protocols | Yes |
| Management Interfaces | Web GUI (HTTP/HTTPS), CLI (SSH/Telnet), Serial Console (RJ-45), SNMP v1/v2c/v3 |
| Security Features | 802.1X,Access Control Lists (ACL),Port Security,RADIUS,TACACS+ |
| Management Type | Managed |
| Remote Management Protocol | HTTP,HTTPS,SSH,Telnet,SNMP |
| Routing Protocol | Static |
| Power & Cooling | |
|---|---|
| Fans | Internal variable-speed fan(s) |
| Power | Internal AC 100-240V, 50-60Hz; PoE budget ~180W |
| Power Supply | Internal AC |
| Physical Characteristics | |
|---|---|
| Dimensions | 1.73 x 17.32 x 10.63 inches |
| Weight | 3.00 |
| Operating Temperature | 0°C to 40°C |
| Miscellaneous | |
|---|---|
| Assembly Required | No |
| Compliance Standards | WEEE, RoHS, CE, FCC, UL |
| Compliant Standards | IEEE 802.3,IEEE 802.3u,IEEE 802.3af,IEEE 802.1Q,IEEE 802.1p,IEEE 802.1X |
| Product Description |
|---|
The Dell PowerConnect 3524P is a network switch designed to provide reliable, high-speed connectivity combined with Power over Ethernet capabilities. It is commonly found in environments where centralized power delivery to network devices such as IP phones, wireless access points, and security cameras is needed. Built for IT professionals managing small to medium business networks, this switch offers flexibility and ease of deployment while maintaining performance. It is often used in office networks, data closets, and other enterprise networking setups that require efficient power management alongside data transmission. Key Features
This switch plays a critical role in maintaining network reliability by integrating power and data delivery within a single system. Its performance and feature set help streamline network infrastructure without compromising on stability or scalability. With consistent throughput and manageable features, the Dell PowerConnect 3524P effectively supports growing network demands while providing a dependable platform for connected devices. |
| Use Cases |
|---|
The Dell PowerConnect 3524P is typically deployed in office networks and enterprise settings where multiple PoE devices require both power and data connectivity. It suits environments that demand efficient network scalability and centralized device management. How It's Used:
By merging power and data transmission capabilities, the switch reduces complexity in network wiring and enhances operational efficiency. This translates into easier scalability and dependable performance in environments managing multiple powered devices. |
