Name: 210-AGZL Dell 32x40G QSFP+ 2x10G SFP+ Layer 3 Managed Switch 2U
Brand: Dell
SKU: 210-AGZL
Price: 80.00 USD
Availability: InStock
Rating: 4.8 (119 reviews)

Product Overview
The Dell Networking S-Series S6100-ON combines high-speed 40G QSFP+ ports with Layer 3 routing capabilities in a compact rack-mountable unit. It fits well in data centers or enterprise networks that demand flexible, high-throughput switching with advanced management features.

General Information
Brand	Dell
Part Number	210-AGZL
Condition	Refurbished

Technical Information
Switch Ports	32 x QSFP+ (40GbE), 2 x SFP+ (10GbE)
Number of Ports	32-Ports
Port Type	10G SFP+, 40G QSFP+
Port Speed	40Gbps,10Gbps
UpLink Ports	2 x SFP+ (10GbE)
POE Support	No
Switching Capacity	2.6 Tbps (non-blocking, full duplex)
Switch Forwarding Rate	5078 Mpps (approx., based on 64-byte frames and 2.6 Tbps)
DRAM	8 GB (typical for ON platforms)
Flash Memory	32 GB (flash/boot storage, typical)
VLAN Support	Yes
Max VLANs Supported	1-4094
Stackable	No
Layer Support	Layer 3
Connector Type	QSFP+, SFP+, Serial Console (RJ-45), USB Console

Performance
Jumbo Frame Support	Up To 9216 Bytes
MAC Address Table Size	128K entries (approx.)

Management and Configuration
Routing Protocols	Static, RIP
Remote Protocols	Yes
Management Interfaces	CLI, SSH, Telnet, SNMP, Web GUI (if OS supports), Serial Console (RJ-45), USB Console
Security Features	ACLs (L2/L3/L4), 802.1X authentication, TACACS+, RADIUS, SSH, Port security, Storm control
Remote Management Protocol	SSH, Telnet, HTTP/HTTPS, SNMPv2/v3
Routing Protocol	Static, RIP, OSPF, OSPFv3, BGP, VRRP, IGMP

Power & Cooling
Fans	Hot-swappable redundant fan modules (front-to-back airflow)
Power	Dual AC power supplies supported (hot-plug, redundant)
Power Supply	Dual hot-plug 1100W AC power supplies (typical configuration)

Physical Characteristics
Dimensions	88.9 x 482.6 x 440 mm (3.5 x 19 x 17.32 in) (2U)
Weight	5.00
Operating Temperature	0°C to 40°C

Miscellaneous
Eco Friendly	Yes
Compliance Standards	CE, FCC
Compliant Standards	IEEE 802.3, IEEE 802.3ae, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad

Product Description
The Dell Networking S-Series S6100-ON is a powerful switch designed for demanding network environments where high throughput and advanced management are key. It often found in data centers and enterprise networks to handle heavy traffic loads efficiently. Built for network engineers and IT professionals, this switch supports complex Layer 3 functions including routing protocols and network segmentation. It is commonly used in scenarios requiring aggregation or core switching within large-scale infrastructures. Key Features High-density QSFP+ ports offer flexible 40Gbps connectivity options Additional SFP+ ports provide versatile 10Gbps links for uplinks or server connections Advanced Layer 3 capabilities support dynamic routing and traffic management Compact 2U design fits standard racks without occupying excessive space ONIE support simplifies network operating system installations and upgrades This switch is typically deployed in data centers as a core or aggregation device, where its high port density and routing features help maintain smooth, large-scale network traffic. Its design ensures reliability and performance under continuous heavy use.

Use Cases
The Dell Networking S-Series S6100-ON is designed for environments that require high-density, high-throughput switching combined with advanced Layer 3 routing capabilities. It is particularly suited to data centers and large-scale enterprise networks where efficient handling of 40G and 10G connections is critical for performance and scalability. How It's Used: Aggregating traffic from multiple 10G and 40G servers in hyperscale data centers to optimize bandwidth and reduce latency. Serving as a top-of-rack switch in virtualized enterprise environments to support multi-tenant network segmentation and routing. Deploying in high-performance computing clusters to provide low-latency, high-throughput interconnects between nodes. Integrating into storage area networks (SANs) to facilitate fast data transfers and management across storage arrays. Utilizing in campus network cores where Layer 3 routing and high port density increase network resilience and scalability. This switch enhances operational efficiency by consolidating high-speed connections with advanced routing in a compact form factor, enabling scalable network architectures that meet the demands of modern data-intensive workloads.
