| Product Overview |
|---|
The Dell PowerSwitch Z-Series Z9100-ON combines high-capacity 100GbE connectivity with Layer 3 management to meet the needs of modern data centers. Its blend of QSFP28 and SFP+ ports makes it adaptable for various network setups, providing both speed and routing flexibility without unnecessary complexity. |
| General Information | |
|---|---|
| Brand | Dell |
| Part Number | 210-AETE |
| Condition | Refurbished |
| Technical Information | |
|---|---|
| Switch Ports | 32 |
| Number of Ports | 32-Ports |
| Port Type | 10G SFP+, 100G QSFP28 |
| Port Speed | 100G,10G |
| UpLink Ports | 2 |
| POE Support | No |
| Switching Capacity | 6.4 Tbps |
| Switch Forwarding Rate | 12.5 Bpps (12,500,000,000 pps) |
| VLAN Support | Yes |
| Max VLANs Supported | 1-4094 |
| Stackable | No |
| Layer Support | Layer 3 |
| Connector Type | QSFP28,SFP+ |
| Performance | |
|---|---|
| Jumbo Frame Support | Up To 9216 Bytes |
| Management and Configuration | |
|---|---|
| Routing Protocols | Static, RIP, OSPF, OSPFv3, BGP, VRRP, HSRP, PIM-SM, IGMP, MLD, Route Maps |
| Remote Protocols | Yes |
| Security Features | 802.1X,Access Control Lists (ACL),RADIUS,TACACS+,SSH,SSL,MAC Filtering,Port Security |
| Remote Management Protocol | SNMPv1/v2/v3,SSH,RMON,Syslog,Telnet |
| Physical Characteristics | |
|---|---|
| Weight | 5.00 |
| Operating Temperature | 0°C to 40°C |
| Miscellaneous | |
|---|---|
| Compliance Standards | RoHS, CE, FCC, UL, TUV, cULus |
| Compliant Standards | IEEE 802.3,IEEE 802.1Q,IEEE 802.1p,IEEE 802.1D,IEEE 802.3ad,IEEE 802.1s |
| Product Description |
|---|
The Dell PowerSwitch Z-Series Z9100-ON is built for high-density, high-performance network environments requiring robust Layer 3 management. It’s often found in data centers where large-scale traffic handling and low latency are critical. Network engineers and IT administrators rely on this switch for its ability to deliver reliable 100GbE connections and flexible routing options. Key Features
This switch is commonly deployed in enterprise networks and cloud data centers where high bandwidth and scalability are essential. It helps maintain smooth data flows in demanding applications such as virtualization, storage networking, and large-scale computing clusters. |
