Product Overview |
|---|
The 17002B Summit X650‑24x switch delivers 24 10 GbE SFP+ ports and 4 1 GbE SFP uplinks in a compact 1U rack-mountable chassis, offering nearly 1 Tbps switching capacity when paired with optional VIMs, advanced Layer 3 routing, stacking to eight units, and enterprise-grade management and security for demanding network infrastructures. |
General Information |
|
|---|---|
| Brand | Extreme Networks |
| Part Number | 17002B |
| Condition | Refurbished |
Technical Information |
|
|---|---|
| Switch Type | Stackable Switch |
| Form Factor | Rack-Mountable |
| Mount Type | 1U Rack |
| Number of Ports | 24-Ports |
| Port Type | 1000Base-X |
| Port Speed | 10 Gbps for SFP+; 1 Gbps for SFP |
| UpLink Ports | 2 × SummitStack stacking ports + 4 × 1 GbE SFP |
| Switching Capacity | 488 Gbps |
| Switch Forwarding Rate | 363 Mpps |
| DRAM | 1 GB |
| Flash Memory | 256 GB |
| Max VLANs Supported | Supports up to 4,094 VLANs |
| Stackable | Yes |
| Layer Support | Layer 2, Layer 3 |
| Connector Type | SFP+, SFP, RS‑232 console, RJ‑45 OOBM, USB |
Performance |
|
|---|---|
| Latency | <2µs |
| Jumbo Frame Support | Up To 9216 Bytes |
| MAC Address Table Size | 32,000 Entries |
Management and Configuration |
|
|---|---|
| Routing Protocols | Static, RIP, OSPF, OSPFv3, BGP, IS-IS, PIM-SM, PIM-DM |
| Remote Protocols | CLI, SNMP v1/v2c/v3, RMON, sFlow, HTTP, Telnet |
| Security Features | ACLs, DiffServ QoS, IPv6 support, VLAN, stacking security |
Physical Characteristics |
|
|---|---|
| Dimensions | 1.7″ × 17.4″ × 26″ |
| Weight | 22.00 |
Product Description |
|---|
The 17002B Summit X650‑24x is a high-performance, fixed-port Layer 3 Ethernet switch designed for demanding data center and enterprise environments. Key Features
This switch excels in campus cores, data center top-of-rack deployments, or service provider aggregation, delivering low latency (<2 μs), extensive VLAN scalability, robust Layer 3 routing, and stack resiliency for multi-unit expansion. |
Use Cases |
|---|
The Extreme Networks X650-24x switch is well-suited for enterprise IT environments requiring high bandwidth and low latency. It is particularly effective in settings where 10GbE connectivity is essential for server aggregation and virtualization workloads, supporting data-intensive applications and network segmentation through extensive VLAN support. How It's Used:
By delivering robust switching capacity and advanced routing capabilities, the X650-24x helps IT teams manage complex traffic patterns while maintaining operational efficiency. Its rack-mount design and stacking features allow networks to scale without sacrificing performance or manageability. |
